FN261-2-06
ActiveTE Connectivity Raychem Cable Protection
FN261-2-06
Deep-Dive with AI
Search across all available documentation for this part.
FN261-2-06
ActiveTE Connectivity Raychem Cable Protection
FN261-2-06
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FN261-2-06 |
|---|---|
| Accomodates a Fuse | True |
| Approval Agency | UL, CQC, CSA, ENEC |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Male Blades - Module |
| Current Rating - Filter | 10 A |
| Filter Type | Filtered (EMI, RFI) - Commercial |
| Fuse Holder, Drawer | Fuse Holder |
| Ingress Protection | IP40 |
| Material Flammability Rating | UL94 V-2 |
| Mounting Type | Panel Mount, Flange |
| Panel Cutout Dimensions [x] | 29 mm |
| Panel Cutout Dimensions [y] | 33 mm |
| Termination | 0.25 in |
| Termination | 6.3 mm |
| Termination | Quick Connect |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 18.24 | |
| 10 | $ 15.81 | |||
| 25 | $ 14.98 | |||
| 60 | $ 14.77 | |||
| 120 | $ 13.03 | |||
| 240 | $ 12.16 | |||
| 480 | $ 11.90 | |||
Description
General part information
Schaffner FN9260/FN261 Series
2 A, Unfiltered, 310 µA Leakage Current @ 250VAC, 50Hz, FASTON, 180 µA Leakage Current @ 120VAC, 60Hz, Schaffner FN9260/FN261, Inlet Filters
