G40H4232212HR
ActiveAmphenol ICC (Commercial Products)
CONN MIN HD SAS RCPT 1X2 72P SMD
G40H4232212HR
ActiveAmphenol ICC (Commercial Products)
CONN MIN HD SAS RCPT 1X2 72P SMD
Description
General part information
G40H Series
72 (36 x 2) Position SAS, Mini HD Receptacle (1x2) Connector Solder Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | G40H4232212HR |
|---|---|
| Connector Pin Configuration (Columns) | 2 pins |
| Connector Pin Configuration (Rows) | 1 pins |
| Connector Style | Receptacle |
| Connector Type | SAS, Mini HD |
| Contact Finish | Gold |
| Contact Finish Thickness | 30 µin |
| Features | Board Lock, Latch Lock |
| Mounting Type | Surface Mount |
| Number of Positions (Columns) | 36 |
| Number of Positions (Rows) | 2 |
| Number of Positions (Total) | 72 |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
