FN7562-100-M8
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 0.47UF 650V AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN7562-100-M8
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 0.47UF 650V AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN7562-100-M8 |
|---|---|
| Capacitance | 0.47 µF |
| Current | 100 A |
| DC Resistance (DCR) (Max) | 0.23 mOhm |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Axial - Threaded Terminals |
| Ratings | Y4 |
| Size / Dimension [diameter] | 32 mm |
| Size / Dimension [diameter] | 1.26 " |
| Size / Dimension [x] | 4.449 " |
| Size / Dimension [x] | 113 mm |
| Thread Size | M20x1 |
| Tolerance | 20 % |
| Voltage - Rated | 650 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 137.27 | |
| 10 | $ 111.28 | |||
| 40 | $ 101.90 | |||
| 80 | $ 98.66 | |||
Description
General part information
FN7562 Series
0.47 µF Feed Through Capacitor 650V 100 A 0.23mOhm (Typ) Axial - Threaded Terminals
Documents
Technical documentation and resources
