FN7562-16-M4
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 0.1UF 650V AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN7562-16-M4 |
|---|---|
| Capacitance | 100000 pF |
| Current | 16 A |
| DC Resistance (DCR) (Max) | 0.62 mOhm |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Axial - Threaded Terminals |
| Ratings | Y4 |
| Size / Dimension [diameter] | 0.787 in |
| Size / Dimension [diameter] | 20 mm |
| Size / Dimension [x] | 2.953 in |
| Size / Dimension [x] | 75 mm |
| Thread Size | M12x1 |
| Tolerance | 20 % |
| Voltage - Rated | 650 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 72.88 | |
| 10 | $ 66.05 | |||
| 40 | $ 61.49 | |||
| 80 | $ 58.53 | |||
Description
General part information
FN7562 Series
0.1 µF Feed Through Capacitor 650V 16 A 0.62mOhm (Typ) Axial - Threaded Terminals
