FN9244EB-6-06
ActiveTE Connectivity Raychem Cable Protection
FN9244EB-6-06
Deep-Dive with AI
Search across all available documentation for this part.
FN9244EB-6-06
ActiveTE Connectivity Raychem Cable Protection
FN9244EB-6-06
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FN9244EB-6-06 |
|---|---|
| Accomodates a Fuse | False |
| Approval Agency | UL, CQC, CSA, ENEC |
| Connector Style | IEC 320-C14 |
| Connector Type | Male Blades, Receptacle |
| Current Rating - Filter | 6 A |
| Features | Earth Line Choke, Front or Rear Side Mount, Bleed Resistor |
| Filter Type | Filtered (EMI, RFI) - Commercial, Medical |
| Ingress Protection | IP40 |
| Material Flammability Rating | UL94 V-2 |
| Mounting Type | Panel Mount, Flange |
| Termination | 0.25 in |
| Termination | 6.3 mm |
| Termination | Quick Connect |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 9.56 | |
| 10 | $ 8.47 | |||
| 25 | $ 8.15 | |||
| 40 | $ 7.82 | |||
| 120 | $ 7.65 | |||
Description
General part information
Schaffner FN9244 Series
6 A, Unfiltered, 0 µA Leakage Current @ 250VAC, 50Hz, FASTON, 0 µA Leakage Current @ 120VAC, 60Hz, Schaffner FN9244, Inlet Filters
