3357-4125

Active

3M (TC)

80610182034 3357-4125=25/EMIJS/DSUB/FLATCAB/MALE/PIN ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsTechnical Data Sheet EN Datasheet +1

3357-4125

Active

3M (TC)

80610182034 3357-4125=25/EMIJS/DSUB/FLATCAB/MALE/PIN ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsTechnical Data Sheet EN Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	3357-4125

Accessory Type	Two Piece Backshell
Cable Exit	180 °
Cable Type	Flat
Color	Gray
Compatible D-Sub Size	HD44pos, 25pos
Compatible Shell Size	B
Hardware	Assembly Hardware
Material	Polyester, Glass Filled
Primary Material	Plastic
Shielding	Shielded

3357 Series

Part	Plating	Primary Material	Number of Positions	Hardware	Shielding	Compatible Shell Size	Material	Compatible D-Sub Size	Features	Cable Exit	Color	Cable Type	Accessory Type
3M (TC) 3357-9215	Nickel	Metal	15	Assembly Hardware Strain Relief	Shielded	A	Metal Steel	15pos HD26pos	Mating Screws 4-40	180 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-4109		Plastic	9	Assembly Hardware	Shielded	E	Polyester Glass Filled	9pos HD15pos		180 °	Gray	Flat	Two Piece Backshell
3M (TC) 3357-6537-1C	Nickel over Copper	Plastic	37	Assembly Hardware Strain Relief	Shielded	C	Acrylonitrile Butadiene Styrene (ABS)	37pos HD62pos	Mating Screws 4-40	45 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-6515-1C	Nickel over Copper	Plastic	15	Assembly Hardware Strain Relief	Shielded	A	Acrylonitrile Butadiene Styrene (ABS)	15pos HD26pos	Mating Screws 4-40	45 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-6225-1C	Nickel over Copper	Plastic		Assembly Hardware Strain Relief	Shielded	B	Acrylonitrile Butadiene Styrene (ABS)	25pos HD44pos	Mating Screws 4-40	180 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-9237	Nickel	Metal	37	Assembly Hardware Strain Relief	Shielded	C	Metal Steel	37pos HD62pos	Mating Screws 4-40	180 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-4115		Plastic	15	Assembly Hardware	Shielded	A	Polyester Glass Filled	15pos HD26pos		180 °	Gray	Flat	Two Piece Backshell
3M (TC) 3357-6237-1C	Nickel over Copper	Plastic	37	Assembly Hardware Strain Relief	Shielded	C	Acrylonitrile Butadiene Styrene (ABS)	37pos HD62pos	Mating Screws 4-40	180 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-9209	Nickel	Metal	9	Assembly Hardware Strain Relief	Shielded	E	Metal Steel	9pos HD15pos	Mating Screws 4-40	180 °	Silver	Round	Two Piece Backshell
3M (TC) 3357-4125		Plastic		Assembly Hardware	Shielded	B	Polyester Glass Filled	25pos HD44pos		180 °	Gray	Flat	Two Piece Backshell

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 11.57
		10	$ 10.03
		25	$ 9.70
Newark	Each	100	$ 17.60
		100	$ 17.60
		250	$ 16.35
		250	$ 16.35
		500	$ 15.28
		500	$ 15.28

Description

General part information

3357 Series

25 Position Two Piece Backshell Connector Gray 180° Shielded

Documents

Technical documentation and resources

Technical Data Sheet EN

Datasheet

Interconnect Catalog

Datasheet
