FN9262A-2-07
ActiveTE Connectivity Raychem Cable Protection
PWR ENT MOD RCPT IEC320-C14 PNL
Deep-Dive with AI
Search across all available documentation for this part.
FN9262A-2-07
ActiveTE Connectivity Raychem Cable Protection
PWR ENT MOD RCPT IEC320-C14 PNL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FN9262A-2-07 |
|---|---|
| Accomodates a Fuse | True |
| Approval Agency | UL, CQC, CSA, ENEC |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Male Blades - Module |
| Current Rating - Filter | 2 A |
| Features | Safety Version |
| Filter Type | Filtered (EMI, RFI) - Commercial |
| Fuse Holder, Drawer | Fuse Holder, Twin Fused |
| Ingress Protection | IP40 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Panel Mount, Flange |
| Panel Cutout Dimensions [x] | 29 mm |
| Panel Cutout Dimensions [y] | 33 mm |
| Termination | Wire Leads |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 22.61 | |
| 1 | $ 22.61 | |||
| 10 | $ 19.21 | |||
| 10 | $ 19.21 | |||
| 25 | $ 18.01 | |||
| 25 | $ 18.01 | |||
| 60 | $ 16.93 | |||
| 60 | $ 16.93 | |||
| 120 | $ 16.12 | |||
| 120 | $ 16.12 | |||
| 300 | $ 15.11 | |||
| 300 | $ 15.11 | |||
| 540 | $ 14.50 | |||
| 540 | $ 14.50 | |||
Description
General part information
Schaffner FN9262 Series
AC Power Entry Modules 4A 7mH 250VAC SnapIn SafetyVersion
