MAXQ622X-0000+

Active

Analog Devices Inc./Maxim Integrated

IC MCU 16BIT 128KB FLASH DIESALE

Search across all available documentation for this part.

Active

Analog Devices Inc./Maxim Integrated

IC MCU 16BIT 128KB FLASH DIESALE

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MAXQ622X-0000+	MAXQ622 Series

Board Type	-	Evaluation Platform
Contents	-	Cable(s), Board(s)
Core Processor	MAXQ20S	MAXQ20, MAXQ20S
Core Size	16-Bit	16-Bit
Mounting Type	Surface Mount	Surface Mount, Fixed
Number of I/O	56	44 - 56
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	0 °C	0 °C
Oscillator Type	Internal	Internal
Package / Case	Die	Die, 64-LQFP
Peripherals	WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset	WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset
Program Memory Size	128 KB	128 KB
Program Memory Type	FLASH	FLASH
RAM Size	6 K	6 K
Speed	12 MHz	12 MHz
Supplier Device Package	Diesale	Die, 64-LQFP (10x10), Diesale
Type	-	MCU 16-Bit
Utilized IC / Part	-	MAXQ622
Voltage - Supply (Vcc/Vdd) [Max]	3.6 V	3.6 V
Voltage - Supply (Vcc/Vdd) [Min]	1.7 V	1.7 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

IC MCU 16BIT 128KB FLASH DIE

Part	Package / Case	Program Memory Type	Core Size	Operating Temperature [Max]	Operating Temperature [Min]	Program Memory Size	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Supplier Device Package	Oscillator Type	Number of I/O	RAM Size	Peripherals	Mounting Type	Speed	Core Processor	Utilized IC / Part	Type	Board Type	Contents
Analog Devices Inc./Maxim Integrated MAXQ622X-2613+	Die	FLASH	16-Bit	70 °C	0 °C	128 KB	3.6 V	1.7 V	Die	Internal	56	6 K	Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT	Surface Mount	12 MHz	MAXQ20
Analog Devices Inc./Maxim Integrated MAXQ622-KIT#														Fixed		MAXQ20S	MAXQ622	MCU 16-Bit	Evaluation Platform	Board(s), Cable(s)
Analog Devices Inc./Maxim Integrated MAXQ622G-0000+	64-LQFP	FLASH	16-Bit	70 °C	0 °C	128 KB	3.6 V	1.7 V	64-LQFP (10x10)	Internal	44	6 K	Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT	Surface Mount	12 MHz	MAXQ20S
Analog Devices Inc./Maxim Integrated MAXQ622X-0000+	Die	FLASH	16-Bit	70 °C	0 °C	128 KB	3.6 V	1.7 V	Diesale	Internal	56	6 K	Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT	Surface Mount	12 MHz	MAXQ20S

General part information

MAXQ20S MAXQ® Microcontroller IC 16-Bit 12MHz 128KB (128K x 8) FLASH Diesale
