MAXQ622G-0000+
ActiveAnalog Devices Inc./Maxim Integrated
IC MCU 16BIT 128KB FLASH 64LQFP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXQ622G-0000+
ActiveAnalog Devices Inc./Maxim Integrated
IC MCU 16BIT 128KB FLASH 64LQFP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXQ622G-0000+ | MAXQ622 Series |
|---|---|---|
| Board Type | - | Evaluation Platform |
| Contents | - | Cable(s), Board(s) |
| Core Processor | MAXQ20S | MAXQ20, MAXQ20S |
| Core Size | 16-Bit | 16-Bit |
| Mounting Type | Surface Mount | Surface Mount, Fixed |
| Number of I/O | 44 | 44 - 56 |
| Operating Temperature [Max] | 70 °C | 70 °C |
| Operating Temperature [Min] | 0 °C | 0 °C |
| Oscillator Type | Internal | Internal |
| Package / Case | 64-LQFP | Die, 64-LQFP |
| Peripherals | WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset | WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset |
| Program Memory Size | 128 KB | 128 KB |
| Program Memory Type | FLASH | FLASH |
| RAM Size | 6 K | 6 K |
| Speed | 12 MHz | 12 MHz |
| Supplier Device Package | 64-LQFP (10x10) | Die, 64-LQFP (10x10), Diesale |
| Type | - | MCU 16-Bit |
| Utilized IC / Part | - | MAXQ622 |
| Voltage - Supply (Vcc/Vdd) [Max] | 3.6 V | 3.6 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 1.7 V | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 9.41 | |
| 10 | $ 6.52 | |||
| 25 | $ 5.77 | |||
| 80 | $ 5.05 | |||
| 230 | $ 4.56 | |||
| 440 | $ 4.32 | |||
| 945 | $ 4.09 | |||
| 2400 | $ 3.98 | |||
MAXQ622 Series
IC MCU 16BIT 128KB FLASH DIE
| Part | Package / Case | Program Memory Type | Core Size | Operating Temperature [Max] | Operating Temperature [Min] | Program Memory Size | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Supplier Device Package | Oscillator Type | Number of I/O | RAM Size | Peripherals | Mounting Type | Speed | Core Processor | Utilized IC / Part | Type | Board Type | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXQ622X-2613+ | Die | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | Die | Internal | 56 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20 | ||||
Analog Devices Inc./Maxim Integrated MAXQ622-KIT# | Fixed | MAXQ20S | MAXQ622 | MCU 16-Bit | Evaluation Platform | Board(s), Cable(s) | ||||||||||||||
Analog Devices Inc./Maxim Integrated MAXQ622G-0000+ | 64-LQFP | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | 64-LQFP (10x10) | Internal | 44 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20S | ||||
Analog Devices Inc./Maxim Integrated MAXQ622X-0000+ | Die | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | Diesale | Internal | 56 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20S |
Description
General part information
MAXQ622 Series
MAXQ20S MAXQ® Microcontroller IC 16-Bit 12MHz 128KB (128K x 8) FLASH 64-LQFP (10x10)
