MAXQ622-KIT#
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ622 EVAL BRD
Deep-Dive with AI
Search across all available documentation for this part.
MAXQ622-KIT#
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ622 EVAL BRD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXQ622-KIT# | MAXQ622 Series |
|---|---|---|
| Board Type | Evaluation Platform | Evaluation Platform |
| Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Core Processor | MAXQ20S | MAXQ20, MAXQ20S |
| Core Size | - | 16-Bit |
| Mounting Type | Fixed | Surface Mount, Fixed |
| Number of I/O | - | 44 - 56 |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | 0 °C |
| Oscillator Type | - | Internal |
| Package / Case | - | Die, 64-LQFP |
| Peripherals | - | WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset |
| Program Memory Size | - | 128 KB |
| Program Memory Type | - | FLASH |
| RAM Size | - | 6 K |
| Speed | - | 12 MHz |
| Supplier Device Package | - | Die, 64-LQFP (10x10), Diesale |
| Type | MCU 16-Bit | MCU 16-Bit |
| Utilized IC / Part | MAXQ622 | MAXQ622 |
| Voltage - Supply (Vcc/Vdd) | - | 3.6 V |
| Voltage - Supply (Vcc/Vdd) | - | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAXQ622 Series
IC MCU 16BIT 128KB FLASH DIE
| Part | Package / Case | Program Memory Type | Core Size | Operating Temperature [Max] | Operating Temperature [Min] | Program Memory Size | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Supplier Device Package | Oscillator Type | Number of I/O | RAM Size | Peripherals | Mounting Type | Speed | Core Processor | Utilized IC / Part | Type | Board Type | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXQ622X-2613+ | Die | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | Die | Internal | 56 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20 | ||||
Analog Devices Inc./Maxim Integrated MAXQ622-KIT# | Fixed | MAXQ20S | MAXQ622 | MCU 16-Bit | Evaluation Platform | Board(s), Cable(s) | ||||||||||||||
Analog Devices Inc./Maxim Integrated MAXQ622G-0000+ | 64-LQFP | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | 64-LQFP (10x10) | Internal | 44 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20S | ||||
Analog Devices Inc./Maxim Integrated MAXQ622X-0000+ | Die | FLASH | 16-Bit | 70 °C | 0 °C | 128 KB | 3.6 V | 1.7 V | Diesale | Internal | 56 | 6 K | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | Surface Mount | 12 MHz | MAXQ20S |
Description
General part information
MAXQ622 Series
MAXQ622 MAXQ® MAXQ20S MCU 16-Bit Embedded Evaluation Board
