1-2366619-2

Active

TE Connectivity Raychem Cable Protection

AUTOMOTIVE CONNECTOR HOUSING, BLUE, LEAVYSEAL SERIES, RECEPTACLE, 62 POSITIONS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet AMP MCP2.8 REC. HOUSING, 39POS , 2.8MM TAB HOUSING, 39POS +1

1-2366619-2

Active

TE Connectivity Raychem Cable Protection

AUTOMOTIVE CONNECTOR HOUSING, BLUE, LEAVYSEAL SERIES, RECEPTACLE, 62 POSITIONS

Deep-Dive with AI

DocumentsDatasheet AMP MCP2.8 REC. HOUSING, 39POS , 2.8MM TAB HOUSING, 39POS +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1-2366619-2

Color	Blue
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Female Socket
Fastening Type	Lever Lock
Features	Sealed
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type	Free Hanging (In-Line), Right Angle
Number of Positions	62
Operating Temperature [Max]	120 °C
Operating Temperature [Min]	-40 °C
Row Spacing	0.157 in
Row Spacing	4 mm

LEAVYSEAL Series

Part	Insulation Material	Connector Type	Features	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Termination	Row Spacing	Row Spacing	Number of Positions	Contact Type	Fastening Type	Color	Contact Shape	Contact Length - Mating	Contact Length - Mating	Style	Insulation Color	Termination	Shrouding	Contact Finish - Mating	Contact Finish - Post	Number of Positions Loaded	Contact Material	Pitch [x]	Pitch [x]	Number of Rows	Note	Row Spacing [Max]	Row Spacing [Max]	Accessory Type	For Use With/Related Products	Row Spacing [x]
TE Connectivity Raychem Cable Protection 1-2366619-2	Polybutylene Terephthalate (PBT) Glass Filled	Receptacle	Sealed	-40 °C	120 °C	Free Hanging (In-Line) Right Angle	Crimp	0.157 in	4 mm	62	Female Socket	Lever Lock	Blue
TE Connectivity Raychem Cable Protection 2-1418362-1	Polybutylene Terephthalate (PBT) Glass Filled	Header	Board Guide Mounting Flange Sealed			Through Hole				62	Tab	Push-Pull		Rectangular	6.7 mm	0.264 in	Board to Cable/Wire	Gray	Solder	Shrouded - 4 Wall	Silver	Tin	All	Copper Alloy
TE Connectivity Raychem Cable Protection 2-1823440-3	Polybutylene Terephthalate (PBT) Glass Filled	Housing for Female Insert	IP67	-40 °C	120 °C	Free Hanging (In-Line)	Crimp			22 positions	Female Socket	Lever Lock	Gray												4 mm	0.157 in	3
TE Connectivity Raychem Cable Protection 1-1823448-2	Polybutylene Terephthalate (PBT) Glass Filled	Plug	Sealed	-40 °C	120 °C		Crimp	0.157 in	4 mm	22 positions	Tab	Slide-On	Black															Contacts Not Included
TE Connectivity Raychem Cable Protection 2-1823402-1
TE Connectivity Raychem Cable Protection 1-2208685-6	Polybutylene Terephthalate (PBT) Glass Filled	Receptacle	IP67	-40 °C	120 °C	Free Hanging (In-Line)	Crimp			31	Female Socket	Lever Lock	Violet														3		0.236 in	6 mm
TE Connectivity Raychem Cable Protection 1-1823402-1	Polybutylene Terephthalate (PBT) Glass Filled	Receptacle	IP67/IP69K Sealed Strain Relief	-40 °C	120 °C	Free Hanging (In-Line)	Crimp			29	Female Socket	Lever Lock	Black															Contacts Not Included
TE Connectivity Raychem Cable Protection 1-1823449-1	Polybutylene Terephthalate (PBT) Glass Filled	Plug	IP67/IP69K Sealed Terminal Position Lock (TPA)	-40 °C	120 °C		Crimp			22 positions	Tab		Black															Contacts Not Included
TE Connectivity Raychem Cable Protection 1-1394052-1			Sealed							21																					Cap (Cover)	LEAVYSEAL Series
TE Connectivity Raychem Cable Protection 2-1718324-1	Polybutylene Terephthalate (PBT) Glass Filled	Plug		-40 °C	120 °C	Free Hanging (In-Line)	Crimp		5.51 mm	62	Tab		Gray												5 mm	0.197 in		Contacts Not Included					0.217 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 24.50
		10	$ 21.45
		44	$ 19.87
		88	$ 19.20
		264	$ 18.14
		528	$ 17.61
Newark	Each	1	$ 18.19
		1000	$ 17.42
		5000	$ 15.48

Description

General part information

LEAVYSEAL Series

62 Position Housing, Housing for Female Terminals, Wire-to-Wire, 4 mm / 5 mm [.157 in / .196 in] Centerline, Sealable, Black, Wire & Cable, LEAVYSEAL

Documents

Technical documentation and resources

Datasheet

AMP MCP2.8 REC. HOUSING, 39POS , 2.8MM TAB HOUSING, 39POS

Product Specifications

Product Change Notice EN

Datasheet
