FN2090LL-20-08
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VDC/VAC 20A CHAS
Deep-Dive with AI
Search across all available documentation for this part.
FN2090LL-20-08
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VDC/VAC 20A CHAS
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FN2090LL-20-08 |
|---|---|
| Applications | General Purpose |
| Approval Agency | UR, CSA, ENEC, CE |
| Configuration | Two Stage |
| Current | 20 A |
| Filter Type | Single Phase |
| Frequency - Operating | 400 Hz |
| Inductance | 2.7 mH |
| Mounting Type | Chassis Mount |
| Operating Temperature [custom] | 100 °C, -25 °C |
| Termination Style | Threaded Post (M4) |
| Voltage - Rated AC | 250 V |
| Voltage - Rated DC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 77.52 | |
| 10 | $ 74.93 | |||
| 30 | $ 72.35 | |||
| 50 | $ 69.76 | |||
| 100 | $ 67.29 | |||
Description
General part information
Schaffner FN2090 Series
20 A Single Phase Filter, Threaded Stud Input, Threaded Stud Output, 250 VAC, Schaffner FN2090, Single Phase Filters
