PGA400Q1EVM
ActiveTexas Instruments
EVAL MODULE FOR PGA400-Q1
Deep-Dive with AI
Search across all available documentation for this part.
PGA400Q1EVM
ActiveTexas Instruments
EVAL MODULE FOR PGA400-Q1
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | PGA400Q1EVM | PGA400 Series |
|---|---|---|
| Contents | Board(s), Cable(s) | Board(s), Cable(s) |
| Current - Supply | - | 13.6 mA |
| Function | Sensor Signal Conditioner | Sensor Signal Conditioner |
| Grade | - | Automotive |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 36-VFQFN Exposed Pad, DSBGA, 36-UFBGA |
| Qualification | - | AEC-Q100 |
| Supplied Contents | Board(s), Cable(s) | Board(s), Cable(s) |
| Supplier Device Package | - | 36-VQFN (6x6), 36-DSBGA (3.66x3.66) |
| Type | Interface | Pressure Sensor, Interface |
| Utilized IC / Part | PGA400-Q1 | PGA400-Q1 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 118.80 | |
PGA400 Series
IC PRESSURE SENSOR SC 36VQFN
| Part | Current - Supply | Supplier Device Package | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Type | Mounting Type | Contents | Utilized IC / Part | Function | Supplied Contents | Qualification | Grade |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments PGA400QRHHTEP | 13.6 mA | 36-VQFN (6x6) | 36-VFQFN Exposed Pad | 125 °C | -40 °C | Pressure Sensor | Surface Mount | ||||||
Texas Instruments PGA400Q1EVM | Interface | Board(s), Cable(s) | PGA400-Q1 | Sensor Signal Conditioner | Board(s), Cable(s) | ||||||||
Texas Instruments PGA400QYZSRQ1 | 13.6 mA | 36-DSBGA (3.66x3.66) | 36-UFBGA, DSBGA | 125 °C | -40 °C | Pressure Sensor | Surface Mount | AEC-Q100 | Automotive |
Description
General part information
PGA400 Series
PGA400-Q1 Sensor Signal Conditioner Interface Evaluation Board
