200-4660-14-1900

Active

CONNECTOR ACCESSORY, EXTRA HOLE PLUG, TEST AND BURN-IN PGA SOCKET KITS, 200-4660 SERIES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Technical Data Sheet EN

200-4660-14-1900

Active

CONNECTOR ACCESSORY, EXTRA HOLE PLUG, TEST AND BURN-IN PGA SOCKET KITS, 200-4660 SERIES

Deep-Dive with AI

DocumentsDatasheet Technical Data Sheet EN

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 4.36
		10	$ 3.96
		25	$ 3.75
		50	$ 3.66
		100	$ 3.49
Newark	N/A	1	$ 0.25
		10	$ 0.25
		25	$ 0.25

Description

General part information

200 Series

Connector Plug For 3M™ PGA Sockets

Documents

Technical documentation and resources

Datasheet

Technical Data Sheet EN

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	200-4660-14-1900	200 Series

Accessory Type	Plug	Plug
Contact Finish - Mating	-	Gold
Contact Finish - Post	-	Gold
Contact Finish Thickness - Mating	-	30 Áin
Contact Finish Thickness - Mating	-	0.76 Ám
Contact Finish Thickness - Post	-	30 µin
Contact Finish Thickness - Post	-	0.76 µm
Contact Material - Mating	-	Beryllium Copper
Contact Material - Post	-	Beryllium Copper
Current Rating (Amps)	-	1 A
For Use With/Related Products	3M™ PGA Sockets	3M™ PGA Sockets
Housing Material	-	Polyethersulfone (PES)
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	-	Through Hole
Number of Positions or Pins (Grid)	-	121 - 625
Number of Positions or Pins (Grid)	-	17
Number of Positions or Pins (Grid)	-	289
Number of Positions or Pins (Grid)	-	17
Operating Temperature [Max]	150 °C	150 °C
Operating Temperature [Min]	-55 °C	-55 °C
Pitch - Mating	-	0.1 in
Pitch - Mating	-	2.54 mm
Pitch - Post	-	2.54 mm
Pitch - Post	-	0.1 in
Termination	-	Solder
Termination Post Length	-	3.3 mm
Termination Post Length	-	0.13 in
Type	-	ZIF (ZIP), PGA

200 Series

CONN SOCKET PGA ZIF 361POS GOLD

Part	Contact Material - Post	Termination Post Length	Termination Post Length	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Mounting Type	Material Flammability Rating	Number of Positions or Pins (Grid)	Current Rating (Amps)	Contact Finish - Post	Housing Material	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Type	Contact Material - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Pitch - Post	Pitch - Post	Number of Positions or Pins (Grid) [custom]	Number of Positions or Pins (Grid) [custom]	Number of Positions or Pins (Grid) [custom]	Accessory Type	For Use With/Related Products
3M 200-6319-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0	361	1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in
3M 200-6313-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0	169	1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in
3M 200-6317-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0		1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in	17	289	17
3M 200-6321-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0	441	1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in
3M 200-4660-14-1900								UL94 V-0					-55 °C	150 °C													Plug	3M™ PGA Sockets
3M 200-6325-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0	625	1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in
3M 200-6311-9UN-1900	Beryllium Copper	3.3 mm	0.13 in	30 Áin	0.76 Ám	Solder	Through Hole	UL94 V-0	121	1 A	Gold	Polyethersulfone (PES)	-55 °C	150 °C	0.1 in	2.54 mm	Gold	PGA, ZIF (ZIP)	Beryllium Copper	30 µin	0.76 µm	2.54 mm	0.1 in
