DP83816AVNG-EX/NOPB
NRND10/100 MBPS INTEGRATED PCI ETHERNET MEDIA ACCESS CONTROLLER & PHYSICAL LAYER (MACPHYTER-II) EXTEND
DP83816AVNG-EX/NOPB
NRND10/100 MBPS INTEGRATED PCI ETHERNET MEDIA ACCESS CONTROLLER & PHYSICAL LAYER (MACPHYTER-II) EXTEND
Description
General part information
DP83816 Series
The DP83816 device is a single-chip 10/100 Mb/s ethernet controller for the PCI bus. It is targeted at low-cost, high-volume PC motherboards, adapter cards, and embedded systems. The DP83816 device fully implements the V2.2 33-MHz PCI bus interface for host communications with power management support. Packet descriptors and data are transferred via bus-mastering, reducing the burden on the host CPU. The DP83816 device can support full-duplex 10/100 Mb/s transmission and reception with minimum interframe gap.
The DP83816 device is a single-chip 10/100 Mb/s ethernet controller for the PCI bus. It is targeted at low-cost, high-volume PC motherboards, adapter cards, and embedded systems. The DP83816 device fully implements the V2.2 33-MHz PCI bus interface for host communications with power management support. Packet descriptors and data are transferred via bus-mastering, reducing the burden on the host CPU. The DP83816 device can support full-duplex 10/100 Mb/s transmission and reception with minimum interframe gap.
Technical Specifications
Parameters and characteristics for this part
| Specification | DP83816AVNG-EX/NOPB |
|---|---|
| Current - Supply | 116 mA |
| Function | Controller |
| Interface | PCI |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | 0 °C |
| Package / Case | 144-LQFP |
| Package Length | 20 mm |
| Package Name | 144-LQFP |
| Package Width | 20 mm |
| Protocol | Ethernet |
| Standards | 10/100 Base-T/TX PHY, IEEE 802.3 |
| Voltage - Supply (Maximum) | 3.6 V |
| Voltage - Supply (Minimum) | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
