Specification	NHD-1.8-160128B

Controller Type	SSD1353
Diagonal Screen Size	1.8 in
Display Type	OLED
Dot Pitch Height	0.2 mm
Dot Pitch Width	0.07 mm
Dot Pixels (Horizontal)	160 pixels
Dot Pixels (Vertical)	128 pixels
Dot Size Height	0.2 mm
Dot Size Width	0.05 mm
Interface	SPI, Parallel
Interface Data Width	8 Bit
Viewing Area Height	30.01 mm
Viewing Area Width	37.01 mm

NHD-1.8 Series

Part	Display Type	Graphics Color	Controller Type	Viewing Area Height	Viewing Area Width	Interface	Interface Data Width	Dot Pixels (Horizontal)	Dot Pixels (Vertical)	Diagonal Screen Size	Display Mode	Touchscreen	Backlight Type	Backlight Color	Dot Size Height	Dot Size Width	Dot Pitch Width	Dot Pitch Height
Newhaven Display Intl NHD-1.8-160128UBC3	OLED	Blue Green Red	SSD1353	29.21 mm	36.22 mm	Parallel SPI	8 Bit	160 pixels	128 pixels	1.8 in
Newhaven Display Intl NHD-1.8-128160EF-CTXI#-T	TFT - Color	Blue Green Red	ILI9163C	37.04 mm	30.03 mm	Parallel	8 Bit	128 pixels	160 pixels	1.8 in	Transmissive	Resistive	LED	White
Newhaven Display Intl NHD-1.8-128160EF-SSXN-F	TFT - Color	Blue Green Red	ILI9163V	35.04 mm	28.03 mm	SPI		128 pixels	160 pixels	1.8 in	Transmissive		LED	White
Newhaven Display Intl NHD-1.8-160128B	OLED		SSD1353	30.01 mm	37.01 mm	Parallel SPI	8 Bit	160 pixels	128 pixels	1.8 in					0.2 mm	0.05 mm	0.07 mm	0.2 mm
Newhaven Display Intl NHD-1.8-160128UF-CTXI#
Newhaven Display Intl NHD-1.91-176176UBC3	OLED	Blue Green Red	SSD1333	35.5 mm	35.5 mm	I2C Parallel SPI	8 Bit	176 pixels	176 pixels	1.91 in
Newhaven Display Intl NHD-1.8-128160EF-SSXN-FT	TFT - Color	Blue Green Red	ILI9163V	35.04 mm	28.03 mm	SPI		128 pixels	160 pixels	1.8 in	Transmissive	Resistive	LED	White
Newhaven Display Intl NHD-1.8-128160ZF-CTXL#	TFT - Color	Blue Green Red		35.04 mm	28.03 mm	Parallel	24 Bit	128 pixels	160 pixels	1.8 in	Transmissive		LED	White
Newhaven Display Intl NHD-1.8-128160EF-CTXI#-FT	TFT - Color	Blue Green Red	ILI9163C	37.04 mm	30.03 mm	Parallel	8 Bit	128 pixels	160 pixels	1.8 in	Transmissive	Resistive	LED	White
Newhaven Display Intl NHD-1.8-128160EF-CTXI#	TFT - Color	Blue Green Red	ILI9163C	35.04 mm	28.03 mm	Parallel	8 Bit	128 pixels	160 pixels	1.8 in	Transmissive		LED	White

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

NHD-1.8-160128B | Datasheet
