S18DLGRXPQ

Active

BANNER ENGINEERING

S18 DAYLIGHT VISIBLE EZ-LIGHT - 18 MM - IP67; TWO COLOR: GREEN RED; 10-30 V DC PNP INPUT; 4 PIN EURO QD ROHS COMPLIANT: YES |BANNER ENGINEERING S18DLGRXPQ

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

S18DLGRXPQ

Active

BANNER ENGINEERING

S18 DAYLIGHT VISIBLE EZ-LIGHT - 18 MM - IP67; TWO COLOR: GREEN RED; 10-30 V DC PNP INPUT; 4 PIN EURO QD ROHS COMPLIANT: YES |BANNER ENGINEERING S18DLGRXPQ

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	S18DLGRXPQ

Current	25 mA
Ingress Protection	NEMA 4X, IP69K, IP67
Lamp Color	Green, Red
Lens Transparency	Diffused
Millicandela Rating [custom]	2.3 mcd
Millicandela Rating [custom]	1.4 mcd
Panel Cutout Dimensions	0.709 in
Panel Cutout Dimensions	18 mm
Panel Cutout Shape	Round
Ratings	DC
Termination Style	Quick Connect
Type	LED
Voltage [Max]	30 V
Voltage [Min]	10 V

S18DL Series

Part	Lens Transparency	Panel Cutout Dimensions	Panel Cutout Dimensions	Current	Ingress Protection	Millicandela Rating [custom]	Millicandela Rating [custom]	Termination Style	Lamp Color	Voltage [Max]	Voltage [Min]	Type	Ratings	Panel Cutout Shape	Millicandela Rating	Wavelength - Peak	Lens Size [diameter]	Wavelength - Peak [custom]	Wavelength - Peak [custom]
BANNER ENGINEERING S18DLGRXPQ	Diffused	0.709 in	18 mm	25 mA	IP67 IP69K NEMA 4X	2.3 mcd	1.4 mcd	Quick Connect	Green Red	30 V	10 V	LED	DC	Round
BANNER ENGINEERING S18DLGRYPQ	Diffused	0.709 in	18 mm	25 mA	IP67 IP69K NEMA 4X			Quick Connect	Green Red Yellow	30 V	10 V	LED	DC	Round	1.2 mcd 1.4 mcd 2.3 mcd
BANNER ENGINEERING S18DLOXXPQ				25 mA	IP67 IP69K				Orange	30 V	10 V	LED	DC			608 nm	16 mm
BANNER ENGINEERING S18DLGRYPT	Clear	0.71 "	18 mm	25 mA	IP67 IP69K NEMA 4X			Screw Terminal	Green Red Yellow	30 V	10 V	LED	DC	Round	1.2 mcd 1.4 mcd 2.3 mcd
BANNER ENGINEERING S18DLRBWPT				25 mA	IP67 IP69K			Screw Terminal	Blue Red White	30 V	10 V	LED	DC				16 mm	625 nm	470 nm
BANNER ENGINEERING S18DLGRYP	Diffused	0.709 in	18 mm	25 mA	IP67 IP69K NEMA 4X			Wire Leads	Green Red Yellow	30 V	10 V	LED	DC	Round	1.2 mcd 1.4 mcd 2.3 mcd
BANNER ENGINEERING S18DLWXXP				25 mA	IP67 IP69K				White	30 V	10 V	LED	DC				16 mm
BANNER ENGINEERING S18DLHWQ	Diffused	0.709 in	18 mm	60 mA	IP67 IP69K NEMA 4X			Quick Connect		30 V	9 V	LED	DC	Round	20 mcd
BANNER ENGINEERING S18DLOXXPT				25 mA	IP67 IP69K			Screw Terminal	Orange	30 V	10 V	LED	DC			608 nm	16 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 41.00
Newark	Each	1	$ 42.00

Description

General part information

S18DL Series

LED Panel Indicator Green, Red Diffused 10V ~ 30V 25mA Quick Connect
