Specification	12-5-3380

Adhesive	Acrylic
Backing	Aluminum Foil
Carrier	Aluminum Foil
Color	Silver
Length (ft)	15 ft
Length (yd)	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	80 °F
Storage/Refrigeration Temperature (Minimum)	60 °F
Tape Type	Aluminum Foil
Temperature Range (Max)	260 °F
Temperature Range (Min)	-30 °F
Thickness	0.0033 in
Thickness - Adhesive	0.0013 in
Thickness - Backing, Carrier	0.002 in
Usage	Reflection, Heat Dissipation
Width	12 in

3380 Series

Part	Shelf Life	Storage/Refrigeration Temperature (Maximum)	Storage/Refrigeration Temperature (Minimum)	Shelf Life Start	Adhesive	Thickness	Length (ft)	Length (yd)	Backing	Carrier	Thickness - Adhesive	Color	Temperature Range (Max)	Temperature Range (Min)	Tape Type	Thickness - Backing, Carrier	Width	Usage
3M (TC) 3380-2-60	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	180 ft	60 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	2 in
3M (TC) 3M 3380 3" X 60YD	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	180 ft	60 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	3 in
3M (TC) 0.125-5-3380 (PK15)	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	0.13 in	Sealing
3M (TC) 3380-1-60	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	180 ft	60 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	1 in	Heat Dissipation Reflection
3M (TC) 12-5-3380	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	12 in	Heat Dissipation Reflection
3M (TC) 3380-6-5	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	6 in	Heat Dissipation Reflection
3M (TC) 3380-0.5-5	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	12.7 mm	Heat Dissipation Reflection
3M (TC) 3380-4-5	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	4 in	Heat Dissipation Reflection
3M (TC) 3380-2-5	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	15 ft	5 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	2 in	Heat Dissipation Reflection
3M (TC) 3M 3380 12" X 60YD	24 Months	80 °F	60 °F	Date of Manufacture	Acrylic	0.0033 in	180 ft	60 yd	Aluminum Foil	Aluminum Foil	0.0013 in	Silver	260 °F	-30 °F	Aluminum Foil	0.002 in	12 in
