QS10.481-A1
ObsoletePULS, LP
AC/DC DIN RAIL SUPPLY 48V 240W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
QS10.481-A1
ObsoletePULS, LP
AC/DC DIN RAIL SUPPLY 48V 240W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | QS10.481-A1 | QS10 Series |
|---|---|---|
| AC Voltage - Input [Max] | 276 VAC | 240 - 276 VAC |
| AC Voltage - Input [Min] | 85 VAC | 85 - 100 VAC |
| Applications | ITE (Commercial), Hazardous Locations | ITE (Commercial), Hazardous Locations |
| Approval Agency | UL, CSA, IEC, ATEX, IECEx | IEC, EAC, UL, CSA, ABS, DNV GL, SEMI, ATEX, IECEx |
| Current - Output (Max) [Max] | 5 A | 5 - 15 A |
| Efficiency | 92 % | 91.8 - 93.5 % |
| Features | PFC, Adjustable Output, Load Sharing | PFC, Conformal Coating, Adjustable Output, Load Sharing |
| Input Type | AC | AC |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 70 °C | 70 °C |
| Operating Temperature [Min] | -10 °C | -25 - 0 °C |
| Power (Watts) | 240 W | 180 - 240 W |
| Size / Dimension [x] | 4.61 " | 4.61 " |
| Size / Dimension [x] | 117 mm | 117 mm |
| Size / Dimension [y] | 2.36 " | 2.36 " |
| Size / Dimension [y] | 60 mm | 60 mm |
| Size / Dimension [z] | 124 mm | 124 mm |
| Size / Dimension [z] | 4.88 " | 4.88 " |
| Standard Number | 61010-2-201, 60950-1, 508, Class I Div 2 | 61010-2-201, 60950-1, 508, Class I Div 2, F47 |
| Voltage - Isolation | 500 V | 500 V |
| Voltage - Output 1 | 48 V | 12 - 48 V |
QS10 Series
AC/DC DIN RAIL SUPPLY 24V 240W
| Part | Applications | AC Voltage - Input [Max] | AC Voltage - Input [Min] | Features | Current - Output (Max) [Max] | Input Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output 1 | Number of Outputs | Voltage - Isolation | Power (Watts) | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Efficiency | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PULS, LP QS10.241-C1 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Conformal Coating, Load Sharing, PFC | 10 A | AC | -25 °C | 70 °C | 24 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 93.5 % | ||
PULS, LP QS10.481-D1 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 5 A | AC | -10 °C | 70 °C | 48 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 92 % | EAC, IEC, UL | 508, 60950-1, 61010-2-201 |
PULS, LP QS10.301 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 8 A | AC | -10 °C | 70 °C | 30 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 93.5 % | ABS, CSA, DNV GL, EAC, IEC, UL | 508, 60950-1, 61010-2-201, Class I Div 2 |
PULS, LP QS10.241 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 10 A | AC | 0 °C | 70 °C | 24 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 93.5 % | ABS, CSA, DNV GL, EAC, IEC, SEMI, UL | 508, 60950-1, 61010-2-201, Class I Div 2, F47 |
PULS, LP QS10.481-A1 | Hazardous Locations, ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 5 A | AC | -10 °C | 70 °C | 48 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 92 % | ATEX, CSA, IEC, IECEx, UL | 508, 60950-1, 61010-2-201, Class I Div 2 |
PULS, LP QS10.121-A1 | Hazardous Locations, ITE (Commercial) | 240 VAC | 100 VAC | Adjustable Output, Load Sharing, PFC | 15 A | AC | -25 °C | 70 °C | 12 V | 1 | 500 V | 180 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 91.8 % | ATEX, CSA, EAC, IEC, IECEx, UL | 508, 60950-1, 61010-2-201, Class I Div 2 |
PULS, LP QS10.241-A1 | Hazardous Locations, ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 10 A | AC | -25 °C | 70 °C | 24 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 93.5 % | ABS, ATEX, CSA, DNV GL, EAC, IEC, IECEx, SEMI, UL | 508, 60950-1, 61010-2-201, Class I Div 2, F47 |
PULS, LP QS10.121 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 15 A | AC | 0 °C | 70 °C | 12 V | 1 | 500 V | 180 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 91.8 % | ABS, CSA, DNV GL, EAC, IEC, SEMI, UL | 508, 60950-1, 61010-2-201, Class I Div 2, F47 |
PULS, LP QS10.481 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 5 A | AC | 0 °C | 70 °C | 48 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 92 % | ABS, CSA, DNV GL, EAC, IEC, UL | 508, 60950-1, 61010-2-201, Class I Div 2 |
PULS, LP QS10.241-D1 | ITE (Commercial) | 276 VAC | 85 VAC | Adjustable Output, Load Sharing, PFC | 10 A | AC | -25 °C | 70 °C | 24 V | 1 | 500 V | 240 W | 124 mm | 2.36 " | 60 mm | 4.88 " | 4.61 " | 117 mm | 93.5 % | EAC, IEC, UL | 508, 60950-1, 61010-2-201 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
QS10 Series
AC/DC DIN RAIL SUPPLY 48V 240W
Documents
Technical documentation and resources
