R125325000W

Active

Radiall USA, Inc.

SMA / STRAIGHT BULKHEAD JACK PAN

Search across all available documentation for this part.

Active

Radiall USA, Inc.

SMA / STRAIGHT BULKHEAD JACK PAN

Technical Specifications

Parameters and characteristics for this part

Specification	R125325000W

Body Finish	Gold
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	SMA
Connector Type	Female Socket, Jack
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	18 GHz
Housing Color	Gold
Impedance	50 Ohms
Mating Cycles	500
Mounting Feature	Bulkhead - Front Side Nut
Number of Ports	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-65 ░C
Shield Termination	Solder
Voltage Rating	250 VDC

Part	Contact Termination	Center Contact Material	Center Contact Plating	Impedance	Shield Termination	Mating Cycles	Housing Color	Number of Ports	Body Finish	Dielectric Material	Mounting Feature	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating	Connector Type	Frequency - Max [Max]	Body Material	Connector Style	Cable Group
Radiall USA, Inc. R125325000W	Solder	Beryllium Copper	Gold	50 Ohms	Solder	500	Gold	1	Gold	Polytetrafluoroethylene (PTFE)	Bulkhead - Front Side Nut	-65 ░C	105 ░C	250 VDC	Female Socket Jack	18 GHz	Stainless Steel	SMA
Radiall USA, Inc. R125322030	Crimp	Beryllium Copper	Gold	50 Ohms	Crimp	500	Gold	1	Gold	Polytetrafluoroethylene (PTFE)	Bulkhead - Front Side Nut	-65 ░C	165 °C	500 V	Female Socket Jack	12.4 GHz	Stainless Steel	SMA	RG-316DS
Radiall USA, Inc. R125326000W	Solder	Beryllium Copper	Gold	50 Ohms	Solder	500	Gold	1	Gold	Polytetrafluoroethylene (PTFE)	Bulkhead - Front Side Nut	-65 ░C	105 ░C	250 VDC	Female Socket Jack	18 GHz	Stainless Steel	SMA	RG-405 (.085" Semi Rigid)
Radiall USA, Inc. R125325000	Solder	Beryllium Copper	Gold	50 Ohms	Solder	500	Gold	1	Gold	Polytetrafluoroethylene (PTFE)	Bulkhead - Front Side Nut	-65 ░C	105 ░C	500 V	Female Socket Jack	18 GHz	Stainless Steel	SMA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

SMA Connector Jack, Female Socket 50 Ohms Panel Mount Solder
