SS-111-G-2

Active

Samtec Inc.

CONN RCPT 11POS 0.1 GOLD PCB

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsSS Datasheet Datasheet

SS-111-G-2

Active

Samtec Inc.

CONN RCPT 11POS 0.1 GOLD PCB

Deep-Dive with AI

DocumentsSS Datasheet Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	SS-111-G-2

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	30 Áin
Contact Finish Thickness - Mating	0.76 Ám
Contact Finish Thickness - Post	10 çin
Contact Finish Thickness - Post	0.25 çm
Contact Length - Post [x]	3.18 mm
Contact Length - Post [x]	0.125 in
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.1 in
Insulation Height	2.54 mm
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type	Through Hole
Number of Positions	11
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Termination	Solder

SS-111 Series

Part	Termination	Number of Rows	Insulation Height	Insulation Height	Mounting Type	Contact Type	Connector Type	Number of Positions	Fastening Type	Insulation Color	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Contact Finish - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Material	Contact Material	Contact Length - Post	Contact Length - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Post
Samtec Inc. SS-111-T-2-N	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold	3.18 mm	0.125 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper
Samtec Inc. SS-111-T-38	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold			Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper	0.18 in	4.57 mm
Samtec Inc. SS-111-T-29	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold			Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper
Samtec Inc. SS-111-S-2	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	10 çin	0.25 çm	Circular	-55 °C	125 °C	All	Gold	3.18 mm	0.125 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper
Samtec Inc. SS-111-TT-1B	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin				-55 °C	125 °C	All						0.51 in	12.95 mm
Samtec Inc. SS-111-T-22	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold	3.18 mm	0.125 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper
Samtec Inc. SS-111-T-5	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold			Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper	0.173 in	4.4 mm
Samtec Inc. SS-111-G-1C	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Gold	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold	6.6 mm	0.26 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper			10 çin	0.25 çm
Samtec Inc. SS-111-S-2-N	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Tin	10 çin	0.25 çm	Circular	-55 °C	125 °C	All	Gold	3.18 mm	0.125 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper
Samtec Inc. SS-111-G-2	Solder	1	0.1 in	2.54 mm	Through Hole	Female Socket	Receptacle	11	Push-Pull	Black	0.1 in	2.54 mm	Gold	30 Áin	0.76 Ám	Circular	-55 °C	125 °C	All	Gold	3.18 mm	0.125 in	Polybutylene Terephthalate (PBT) Glass Filled	Beryllium Copper			10 çin	0.25 çm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 3.71
		10	$ 3.37
		100	$ 2.97
		500	$ 2.52
		1000	$ 2.15
		5000	$ 1.96

Description

General part information

SS-111 Series

11 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold

Documents

Technical documentation and resources

SS Datasheet

Datasheet
