HDB-M4 Series

Manufacturer: Amphenol Aerospace Operations

Catalog

MOTHER BOARD 80POS

Part	Operating Temperature (Max)	Operating Temperature (Min)	Current Rating	Mounting Type	Number of Columns	Number of Positions	Contact Finish Thickness	Number of Rows	Features	Color	Connector Type	Number of Positions Loaded	Termination	Connector Style	Pitch	Connector Usage	Contact Finish
Amphenol Aerospace Operations HDB-M4-080M222X	125 °C	-65 °C	2 A	Through Hole	10	80	30 µin	8	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-060M242X	125 °C	-65 °C	2 A	Through Hole	10	60	30 µin	6	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-120M232X	125 °C	-65 °C	2 A	Through Hole	10	120	30 µin	12	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-080M242X	125 °C	-65 °C	2 A	Through Hole	10	80	30 µin	8	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-120M246X	125 °C	-65 °C	2 A	Through Hole	10	120	100 µin	12	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Tin-Lead
Amphenol Aerospace Operations HDB-M4-060M222X	125 °C	-65 °C	2 A	Through Hole	10	60	30 µin	6	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-080M232X	125 °C	-65 °C	2 A	Through Hole	10	80	30 µin	8	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-120M242X	125 °C	-65 °C	2 A	Through Hole	10	120	30 µin	12	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Gold
Amphenol Aerospace Operations HDB-M4-080M246X	125 °C	-65 °C	2 A	Through Hole	10	80	100 µin	8	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Tin-Lead
Amphenol Aerospace Operations HDB-M4-060M246X	125 °C	-65 °C	2 A	Through Hole	10	60	100 µin	6	Jackscrew	Black	Female Sockets Receptacle	All	Solder	High Density (HDC HDI HPC)	0.07 in	Backplane Motherboard	Tin-Lead
