ERF8-070 Series

Catalog

CONN SOCKET 140POS SMD GOLD

Part	Features	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Number of Rows	Pitch [x]	Pitch [x]	Mated Stacking Heights	Mounting Type	Height Above Board [z]	Height Above Board [z]	Contact Finish	Connector Type	Height Above Board	Height Above Board
Samtec Inc. ERF8-070-07.0-S-DV-EGP-TR	Board Guide	0.76 Ám	30 Áin	140	2	0.8 mm	0.031 in	9 mm 12 mm 15 mm 16 mm 22 mm	Surface Mount	0.285 in	7.24 mm	Gold	Outer Shroud Contacts Socket
Samtec Inc. ERF8-070-03-S-D-RA-TR	Board Guide Mounting Flange	0.76 Ám	30 Áin	140	2	0.8 mm	0.031 in		Surface Mount Right Angle			Gold	Outer Shroud Contacts Socket	6.25 mm	0.246 in
Samtec Inc. ERF8-070-01-L-D-RA-EGP-TR	Board Guide Mounting Flange	0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in		Surface Mount Right Angle			Gold	Outer Shroud Contacts Socket	6.25 mm	0.246 in
Samtec Inc. ERF8-070-05.0-L-DV-K-TR	Board Guide Pick and Place	0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in	7 mm 10 mm 13 mm 14 mm 20 mm	Surface Mount			Gold	Outer Shroud Contacts Socket	5.33 mm	0.21 in
Samtec Inc. ERF8-070-05.0-S-DV-L-K-TR	Board Guide Latches Pick and Place	0.76 Ám	30 Áin	140	2	0.8 mm	0.031 in	7 mm 10 mm 13 mm 14 mm 20 mm	Surface Mount			Gold	Outer Shroud Contacts Socket	5.33 mm	0.21 in
Samtec Inc. ERF8-070-07.0-L-DV-EGP-K-TR	Board Guide Pick and Place	0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in	9 mm 12 mm 15 mm 16 mm 22 mm	Surface Mount	0.285 in	7.24 mm	Gold	Outer Shroud Contacts Socket
Samtec Inc. ERF8-070-03-L-D-RA-TR	Board Guide Mounting Flange	0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in		Surface Mount Right Angle			Gold	Outer Shroud Contacts Socket	6.25 mm	0.246 in
Samtec Inc. ERF8-070-01-L-D-EM2-TR		0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in		Board Edge Straddle Mount			Gold	Outer Shroud Contacts Socket
Samtec Inc. ERF8-070-07.0-S-DV-K-TR	Board Guide Pick and Place	0.76 Ám	30 Áin	140	2	0.8 mm	0.031 in	9 mm 12 mm 15 mm 16 mm 22 mm	Surface Mount	0.285 in	7.24 mm	Gold	Outer Shroud Contacts Socket
Samtec Inc. ERF8-070-05.0-L-DV-L-K-TR	Board Guide Latches Pick and Place	0.25 Ám	10 Áin	140	2	0.8 mm	0.031 in	7 mm 10 mm 13 mm 14 mm 20 mm	Surface Mount			Gold	Outer Shroud Contacts Socket	5.33 mm	0.21 in
