CSD87381 Series

Catalog

30-V, N CHANNEL SYNCHRONOUS BUCK NEXFET™ POWER MOSFET, 3 MM X 2.5 MM LGA, 15 A

Part	Gate Charge (Max)	Package / Case	Channel Count	Configuration - Features	Configuration	Package Name	Package Length	Package Width	Vgs(th) (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Rds On (Max)	Drain to Source Voltage (Vdss)	FET Feature	Power - Max	Mounting Type	Current - Continuous Drain (Id)	Input Capacitance (Ciss) (Max)	Technology	Total Output Count	Output Type	Non-Isolated Output Count	Board Type	Supplied Contents	Voltage - Input (Maximum)	Voltage - Input (Minimum)	Voltage - Output	Current - Output	Utilized IC / Part	Regulator Topology	Frequency - Switching	Main Purpose	Contents
Texas Instruments CSD87381P	5 nC	5-LGA	2	Half Bridge	N-Channel	5-PTAB	3 mm	2.5 mm	1.9 V	-55 °C	150 °C	16.3 mOhm	30 V	Logic Level Gate	4 VA	Surface Mount	15 A	564 pF	MOSFET (Metal Oxide)
Texas Instruments CSD87381PEVM-603																				1	Non-Isolated	1 count	Fully Populated	Board(s)	20 V	8 V	1.35 V	15 A	CSD87381P TPS51219	Buck	300 kHz	DC/DC Step Down	Board
Texas Instruments CSD87381PT	5 nC	5-LGA	2	Half Bridge	N-Channel	5-PTAB	3 mm	2.5 mm	1.9 V	-55 °C	150 °C	16.3 mOhm	30 V	Logic Level Gate	4 VA	Surface Mount	15 A	564 pF	MOSFET (Metal Oxide)
