9407 060U500
ActiveMULTIPAIR CABLE, POWER LIMITED TRAY, UNSHIELDED, 1 PAIR, 22 AWG, 500 FT, 152.4 M
Deep-Dive with AI
Search across all available documentation for this part.
9407 060U500
ActiveMULTIPAIR CABLE, POWER LIMITED TRAY, UNSHIELDED, 1 PAIR, 22 AWG, 500 FT, 152.4 M
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 9407 060U500 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 30 AWG |
| Jacket (Insulation) Diameter [diameter] | 0.198 in |
| Jacket (Insulation) Diameter [diameter] | 5.03 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.94 mm |
| Jacket (Insulation) Thickness | 0.037 in |
| Jacket Color | Chrome |
| Length [x] | 500 ' |
| Length [x] | 152.4 m |
| Number of Conductors | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -30 ░C |
| Wire Gauge | 22 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
9407 Series
The 9407 060U500 is a 1-pair Unshielded Cable with 22AWG stranded tinned copper conductors and a PVC insulation. The 9407 series multi-conductor 300V power-limited tray cable comes with a chrome PVC outer jacket. Belden multi-conductor cable delivers low voltage analog data and signal transmission within enclosures from controllers and I/O's to devices such as temperature and pressure sensors, relays, valves, meters, thermocouples, solenoids, actuators, contactors, push buttons and alarms.
