9407 060U1000
ActiveBelden Inc.
CABLE 2COND 22AWG CHROMEE
Deep-Dive with AI
Search across all available documentation for this part.
9407 060U1000
ActiveBelden Inc.
CABLE 2COND 22AWG CHROMEE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 9407 060U1000 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 30 AWG |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.198 in |
| Jacket (Insulation) Diameter [diameter] | 5.03 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.94 mm |
| Jacket (Insulation) Thickness | 0.037 in |
| Jacket Color | Chrome |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -30 ░C |
| Ratings | UL Style 2464 |
| Wire Gauge | 22 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1000 | $ 1.11 | |
| 2000 | $ 1.06 | |||
| 3000 | $ 1.03 | |||
| 5000 | $ 0.99 | |||
| 7000 | $ 0.96 | |||
| 10000 | $ 0.95 | |||
Description
General part information
9407 Series
2 (1 Pair Twisted) Conductor Multi-Conductor Cable Chrome 22 AWG 1000.0' (304.8m)
