ALS30A472DA063

Active

KEMET

ELECTROLYTIC CAPACITOR, LONG LIFE, ALS30 SERIES, 4700 F, 20%, 63 V, 36 MM, 0.036 OHM ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet ALS30A472DA063 Spec +2

ALS30A472DA063

Active

KEMET

ELECTROLYTIC CAPACITOR, LONG LIFE, ALS30 SERIES, 4700 F, 20%, 63 V, 36 MM, 0.036 OHM ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheet ALS30A472DA063 Spec +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ALS30A472DA063

Applications	General Purpose
Capacitance	4700 µF
ESR (Equivalent Series Resistance)	36 mOhm
Height - Seated (Max) [Max] [z]	2.047 in
Height - Seated (Max) [Max] [z]	52 mm
Impedance	28 mOhms
Lead Spacing	0.504 in
Lead Spacing	12.8 mm
Lifetime @ Temp.	11000 Hrs
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Screw Terminals
Polarization	Polar
Ripple Current @ High Frequency	7.4 A
Ripple Current @ Low Frequency	6.7 A
Size / Dimension [diameter]	1.417 in
Size / Dimension [diameter]	36 mm
Tolerance	20 %
Voltage - Rated	63 V

ALS30A Series

Part	Lifetime @ Temp.	Impedance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Polarization	Package / Case	Ripple Current @ Low Frequency	Capacitance	Applications	Tolerance	Lead Spacing	Lead Spacing	Ripple Current @ High Frequency	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension
KEMET ALS30A472DA063	11000 Hrs	28 mOhms	2.047 in	52 mm	Polar	Radial Can - Screw Terminals	6.7 A	4700 µF	General Purpose	20 %	0.504 in	12.8 mm	7.4 A	36 mOhm	1.417 in	36 mm	Chassis Mount	63 V	85 °C	-40 °C
KEMET ALS30A152KF450	18000 Hrs	65 mOhms			Polar	Radial Can - Screw Terminals		1.5 mF	General Purpose	20 %	0.874 in	22.2 mm		93 mOhm	2.008 "	51 mm	Chassis Mount	450 V	85 °C	-40 °C	107 mm	4.213 in
KEMET ALS30A473DF025	11000 Hrs	7 mOhms	4.134 "	105 mm	Polar	Radial Can - Screw Terminals	16.6 A	47 mF	General Purpose	20 %	0.504 in	12.8 mm	17.4 A	9 mOhm	1.417 in	36 mm	Chassis Mount	25 VDC	85 °C	-40 °C
KEMET ALS30A222KF400	18000 Hrs	56 mOhms			Polar	Radial Can - Screw Terminals	8.4 A	2200 µF	General Purpose	20 %	0.874 in	22.2 mm	13.5 A	78 mOhm	2.008 "	51 mm	Chassis Mount	400 V	85 °C	-40 °C	107 mm	4.213 in
KEMET ALS30A102DE250	11000 Hrs	89 mOhms	3.228 in	82 mm	Polar	Radial Can - Screw Terminals	5 A	1000 µF	General Purpose	20 %	0.504 in	12.8 mm	7.4 A	117 mOhm	1.417 in	36 mm	Chassis Mount	250 V	85 °C	-40 °C
KEMET ALS30A152NF500	20000 Hrs	65 mOhms			Polar	Radial Can - Screw Terminals	10.6 A	1.5 mF	General Purpose	20 %	1.252 in	31.8 mm	17 A	120 mOhm	3.032 in	77 mm	Chassis Mount	500 V	85 °C	-40 °C	107 mm	4.213 in
KEMET ALS30A332NF400	20000 Hrs	36 mOhms	4.134 "	105 mm	Polar	Radial Can - Screw Terminals	13.4 A	3.3 mF	General Purpose	20 %	1.252 in	31.8 mm	21.3 A	49 mOhm	3.031 "	77 mm	Chassis Mount	400 V	85 °C	-40 °C
KEMET ALS30A102KE450	18000 Hrs	79 mOhms	3.307 in	84 mm	Polar	Radial Can - Screw Terminals		1000 µF	General Purpose	20 %	0.874 in	22.2 mm		118 mOhm	2.008 "	51 mm	Chassis Mount	450 V	85 °C	-40 °C
KEMET ALS30A472NP400	20000 Hrs	24 mOhms	5.748 in	146 mm	Polar	Radial Can - Screw Terminals	18 A	4700 µF	General Purpose	20 %	1.252 in	31.8 mm	26 A	33 mOhm	3.031 "	77 mm	Chassis Mount	400 V	85 °C	-40 °C
KEMET ALS30A222MF400	19000 Hrs	44 mOhms			Polar	Radial Can - Screw Terminals	11.2 A	2200 µF	General Purpose	20 %	1.122 in	28.5 mm	18.8 A	62 mOhm	2.598 in		Chassis Mount	400 V	85 °C	-40 °C	107 mm	4.213 in	66 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 12.70
		10	$ 11.74
		50	$ 10.16
		100	$ 9.14
		500	$ 8.44
		1000	$ 7.94
Newark	Each	1	$ 16.48
		10	$ 12.60
		25	$ 11.87
		50	$ 11.12
		100	$ 10.90

Description

General part information

ALS30A Series

4700 µF 63 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 36mOhm @ 100Hz 11000 Hrs @ 85°C
