MP2-H030-51S1-S-LR

Active

80000916652 MP2-H030-51S1-S-LR=MP2/HDR/VERT/30P/5R/ST/4.60MM/SHDR/30PDNI/R

Search across all available documentation for this part.

Active

80000916652 MP2-H030-51S1-S-LR=MP2/HDR/VERT/30P/5R/ST/4.60MM/SHDR/30PDNI/R

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

30 Connector Header, Male Pins Through Hole Beige Futurebus+®

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	MP2-H030-51S1-S-LR	MP2-H030 Series

Color	Beige	Beige
Connector Style	Futurebus+®	Futurebus+®
Connector Type	Header, Male Pins	Header, Male Pins
Connector Usage	Backplane	Backplane
Contact Finish	Gold	Gold
Contact Finish Thickness	3 Áin	3 - 30 Áin
Contact Finish Thickness	0.076 Ám	0.076 - 0.76 Ám
Current Rating (Amps)	1.5 A	1.5 A
Features	Mating Guide, Board Guide	Mating Guide, Board Guide
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Through Hole	Through Hole
Number of Positions	30	30
Number of Positions Loaded	All	All
Number of Rows	5	5
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Pitch [x]	0.079 in	0.079 in
Pitch [x]	2 mm	2 mm
Termination	Solder	Solder, Press-Fit

CONN HEADER FUTUREBUS+ 30POS PCB

Part	Contact Finish	Connector Style	Color	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Current Rating (Amps)	Mounting Type	Pitch [x]	Pitch [x]	Connector Usage	Number of Positions	Number of Positions Loaded	Material Flammability Rating	Number of Rows	Features	Operating Temperature [Min]	Operating Temperature [Max]	Termination
3M MP2-H030-52S1-S-LR	Gold	Futurebus+®	Beige	3 Áin	0.076 Ám	Header, Male Pins	1.5 A	Through Hole	0.079 in	2 mm	Backplane	30	All	UL94 V-0	5	Board Guide, Mating Guide	-55 °C	125 °C	Solder
3M MP2-H030-51P1-S-KR	Gold	Futurebus+®	Beige	30 Áin	0.76 Ám	Header, Male Pins	1.5 A	Through Hole	0.079 in	2 mm	Backplane	30	All	UL94 V-0	5	Board Guide, Mating Guide	-55 °C	125 °C	Press-Fit
3M MP2-H030-51S1-S-LR	Gold	Futurebus+®	Beige	3 Áin	0.076 Ám	Header, Male Pins	1.5 A	Through Hole	0.079 in	2 mm	Backplane	30	All	UL94 V-0	5	Board Guide, Mating Guide	-55 °C	125 °C	Solder
3M MP2-H030-54P1-S-TR30	Gold	Futurebus+®	Beige	3 Áin	0.076 Ám	Header, Male Pins	1.5 A	Through Hole	0.079 in	2 mm	Backplane	30	All	UL94 V-0	5	Board Guide, Mating Guide	-55 °C	125 °C	Press-Fit
