8428-12

Active

3M (TC)

3M COLD SHRINK INSULATOR 8428-12, TAPE, WIRE, UNISHIELD, 1 KV, STANDARD, 10 PER CASE

Search across all available documentation for this part.

Active

3M (TC)

3M COLD SHRINK INSULATOR 8428-12, TAPE, WIRE, UNISHIELD, 1 KV, STANDARD, 10 PER CASE

Technical Specifications

Parameters and characteristics for this part

Specification	8428-12

Color	Black
Diameter [Max] [diameter]	49.3 mm
Diameter [Max] [diameter]	1.94 "
Diameter [Min] [diameter]	24.1 mm
Diameter [Min] [diameter]	0.95 "
Length [x]	304.8 mm
Length [x]	1 ft
Length [x]	12 "
Material	Ethylene Propylene Rubber (EPR)
Shelf Life	60 Months
Shelf Life Start	Date of Manufacture
Type	Tubing

Part	Color	Material	Diameter [Min] [diameter]	Diameter [Max] [diameter]	Diameter [Min] [diameter]	Diameter [Max] [diameter]	Shelf Life Start	Type	Length [x]	Length [x]	Length [x]	Shelf Life
3M (TC) 8428-12P	Black	Ethylene Propylene Rubber (EPR)	24.1 mm	49.3 mm	0.95 "	1.94 "	Date of Manufacture	Tubing	304.8 mm	1 ft	12 "	60 Months
3M (TC) 8428-12	Black	Ethylene Propylene Rubber (EPR)	24.1 mm	49.3 mm	0.95 "	1.94 "	Date of Manufacture	Tubing	304.8 mm	1 ft	12 "	60 Months
3M (TC) 8428-18	Black	Ethylene Propylene Rubber (EPR)	24.1 mm	49.3 mm	0.95 "	1.94 "	Date of Manufacture	Tubing	457.2 mm	1.5 ft		60 Months
3M (TC) 8428-12M	Black	Ethylene Propylene Rubber (EPR)	24.1 mm	49.3 mm	0.95 "	1.94 "	Date of Manufacture	Tubing	304.8 mm	1 ft	12 "	60 Months

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Black Cold Shrink Tubing 0.95" ~ 1.94" (24.1mm ~ 49.3mm) X 1.000' (304.80mm, 12.00")
