APT1232AX
ActivePanasonic Electric Works
PHOTOTRIAC COUPLER 600V 6DIP
Deep-Dive with AI
Search across all available documentation for this part.
APT1232AX
ActivePanasonic Electric Works
PHOTOTRIAC COUPLER 600V 6DIP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | APT1232AX |
|---|---|
| Approval Agency | cUR, VDE |
| Current - DC Forward (If) (Max) | 50 mA |
| Current - Hold (Ih) | 3.5 mA |
| Current - LED Trigger (Ift) (Max) [Max] | 10 mA |
| Current - On State (It (RMS)) (Max) | 100 mA |
| Mounting Type | Surface Mount |
| Number of Channels | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | Triac |
| Package / Case | 6-SMD (5 Leads), Gull Wing |
| Static dV/dt (Min) [Min] | 500 V/µs |
| Supplier Device Package | 6-DIP Gull Wing |
| Turn On Time | 100 µs |
| Voltage - Forward (Vf) (Typ) | 1.21 V |
| Voltage - Off State | 600 V |
| Zero Crossing Circuit | True |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.09 | |
| 10 | $ 1.39 | |||
| 100 | $ 1.07 | |||
| 500 | $ 0.97 | |||
| Digi-Reel® | 1 | $ 2.09 | ||
| 10 | $ 1.39 | |||
| 100 | $ 1.07 | |||
| 500 | $ 0.97 | |||
| Tape & Reel (TR) | 1000 | $ 0.83 | ||
| 2000 | $ 0.79 | |||
| 5000 | $ 0.77 | |||
| 10000 | $ 0.76 | |||
Description
General part information
APT1232 Series
Optoisolator Triac Output 5000Vrms 1 Channel 6-DIP Gull Wing
Documents
Technical documentation and resources
No documents available
