FN402-1.6-02
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 1.6A TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN402-1.6-02
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 1.6A TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN402-1.6-02 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CSA, ENEC, UR |
| Configuration | Single Stage |
| Current | 1.6 A |
| Filter Type | Single Phase |
| Frequency - Operating | 400 Hz |
| Inductance | 6 mH |
| Mounting Type | Through Hole |
| Operating Temperature [custom] | 100 °C, -25 °C |
| Termination Style | PC Pins |
| Voltage - Rated AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 11.60 | |
| 10 | $ 9.46 | |||
| 25 | $ 8.72 | |||
| 40 | $ 8.37 | |||
| 80 | $ 7.87 | |||
| 230 | $ 7.16 | |||
| 440 | $ 6.92 | |||
Description
General part information
Schaffner FN402 Series
Single Phase EMC/EMI Line Filter 1.6 A 250V DC ~ 400Hz Single Stage PC Pins
