BD-05PMMP-LC7001

Active

Amphenol LTW

CIRCULAR CONNECTOR, STANDARD (B) SERIES, PANEL MOUNT PLUG, 5 CONTACTS

Search across all available documentation for this part.

Active

Amphenol LTW

CIRCULAR CONNECTOR, STANDARD (B) SERIES, PANEL MOUNT PLUG, 5 CONTACTS

Technical Specifications

Parameters and characteristics for this part

Part	Contact Material	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Connector Type	Voltage Rating	Primary Material	Mounting Feature	Current Rating (Amps)	Shielding	Termination	Color	Contact Finish - Mating	Insert Material	Ingress Protection	Shell Material
Amphenol LTW BD-05PMMP-LC7001	Copper Alloy	Keyed	-40 °C	105 ░C	B	Male Pins Receptacle	250 VDC	Plastic	Bulkhead - Front Side Nut	5 A	Unshielded	Solder	Black	Gold	Thermoplastic	IP67 - Dust Tight Waterproof
Amphenol LTW BD-05PMMP-SC7001	Copper Alloy	Keyed	-40 °C	105 ░C	B	Male Pins Receptacle	250 VDC	Plastic	Bulkhead - Front Side Nut	5 A	Unshielded	Solder	Black	Gold	Polyamide (PA) Nylon Glass Filled	IP67 - Dust Tight Waterproof	Glass Filled Nylon Polyamide (PA)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Position Circular Connector Receptacle, Male Pins Solder
