CDCE949PERF-EVM
ActiveTexas Instruments
EVAL MOD PERFORMANCE FOR CDCE949
Deep-Dive with AI
Search across all available documentation for this part.
CDCE949PERF-EVM
ActiveTexas Instruments
EVAL MOD PERFORMANCE FOR CDCE949
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | CDCE949PERF-EVM | CDCE949 Series |
|---|---|---|
| Differential - Input:Output | - | False |
| Differential - Input:Output | - | False |
| Divider/Multiplier | - | Yes/No |
| Frequency - Max | - | 230 MHz |
| Function | Clock Generator | Clock Generator |
| Grade | - | Automotive |
| Input | - | LVCMOS, Crystal |
| Mounting Type | - | Surface Mount |
| Number of Circuits | - | 1 |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 85 - 125 °C |
| Output | - | LVCMOS |
| Package / Case | - | 4.4 mm |
| Package / Case | - | 0.173 " |
| Package / Case | - | 24-TSSOP |
| PLL | - | Yes with Bypass |
| Qualification | - | AEC-Q100 |
| Ratio - Input:Output | - | 1 |
| Ratio - Input:Output | - | 9 |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-TSSOP |
| Type | Timing | PLL Clock Generator, Spread Spectrum Clock Driver, Timing |
| Utilized IC / Part | CDCE949PERF | CDCE949PERF |
| Voltage - Supply | - | 1.7 V |
| Voltage - Supply | - | 1.9 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 178.80 | |
CDCE949 Series
IC PLL CLOCK GENERATOR 24TSSOP
| Part | Number of Circuits | Ratio - Input:Output [custom] | Ratio - Input:Output [custom] | Package / Case [y] | Package / Case [y] | Package / Case | Type | Input | Operating Temperature [Min] | Operating Temperature [Max] | PLL | Supplier Device Package | Voltage - Supply [Min] | Voltage - Supply [Max] | Frequency - Max [Max] | Output | Mounting Type | Divider/Multiplier | Differential - Input:Output [custom] | Differential - Input:Output [custom] | Qualification | Grade | Supplied Contents | Utilized IC / Part | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments CDCE949PWRG4 | 1 | 1 | 9 | 4.4 mm | 0.173 " | 24-TSSOP | PLL Clock Generator | Crystal, LVCMOS | -40 °C | 85 °C | Yes with Bypass | 24-TSSOP | 1.7 V | 1.9 V | 230 MHz | LVCMOS | Surface Mount | Yes/No | |||||||
Texas Instruments CDCE949QPWRQ1 | 1 | 1 | 9 | 4.4 mm | 0.173 " | 24-TSSOP | Spread Spectrum Clock Driver | Crystal, LVCMOS | -40 °C | 125 °C | Yes with Bypass | 24-TSSOP | 1.7 V | 1.9 V | 230 MHz | LVCMOS | Surface Mount | Yes/No | AEC-Q100 | Automotive | |||||
Texas Instruments CDCE949PERF-EVM | Timing | Board(s) | CDCE949PERF | Clock Generator | |||||||||||||||||||||
Texas Instruments CDCE949PW | 1 | 1 | 9 | 4.4 mm | 0.173 " | 24-TSSOP | PLL Clock Generator | Crystal, LVCMOS | -40 °C | 85 °C | Yes with Bypass | 24-TSSOP | 1.7 V | 1.9 V | 230 MHz | LVCMOS | Surface Mount | Yes/No |
