PT6308S

Active

Texas Instruments

DC DC CONVERTER 1.2V 3A

Search across all available documentation for this part.

Active

Texas Instruments

DC DC CONVERTER 1.2V 3A

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	PT6308S	PT6308 Series

Applications	ITE (Commercial)	ITE (Commercial)
Current - Output (Max) [Max]	3 A	3 A
Mounting Type	Through Hole	Through Hole, Through Hole, Right Angle
Number of Outputs	1	1
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	0 °C	0 °C
Package / Case	12-SIP Module	12-SIP Module
Size / Dimension	-	17 mm
Size / Dimension	-	2.06 in
Size / Dimension	-	0.38 in
Size / Dimension	-	52.3 mm
Size / Dimension	-	0.67 in
Size / Dimension	-	9.7 mm
Type	Non-Isolated PoL Module	Non-Isolated PoL Module
Voltage - Input (Max) [Max]	6 V	6 V
Voltage - Input (Min) [Min]	4.5 V	4.5 V
Voltage - Output 1	1.2 V	1.2 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	11	$ 28.20

DC DC CONVERTER 1.2V 3A

Part	Package / Case	Voltage - Input (Min) [Min]	Voltage - Output 1	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Mounting Type	Number of Outputs	Type	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]
Texas Instruments PT6308S	12-SIP Module	4.5 V	1.2 V	6 V	3 A	Through Hole	1	Non-Isolated PoL Module	70 °C	0 °C	ITE (Commercial)
Texas Instruments PT6308A	12-SIP Module	4.5 V	1.2 V	6 V	3 A	Through Hole, Right Angle	1	Non-Isolated PoL Module	70 °C	0 °C	ITE (Commercial)	17 mm	2.06 in	0.38 in	52.3 mm	0.67 in	9.7 mm

General part information

Non-Isolated PoL Module DC DC Converter 1 Output 1.2V 3A 4.5V - 6V Input
