Specification	C091 31H105 101 2

Color	Silver
Connector Type	Male Pins, Plug
Contact Finish - Mating	Silver
Current Rating	7 A
Fastening Type	Threaded
Features	Stereo, Strain Relief
Ingress Protection Description	Water Resistant, Dust Tight, Waterproof
Ingress Protection IP Rating	IP69K, IP65, IP67
Mounting Type	Free Hanging (In-Line)
Number of Positions	5
Operating Temperature (Max)	100 °C
Operating Temperature (Min)	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-5(S)
Shielding	Shielded
Termination	Solder Cup
Voltage Rating	60 V

C091 31H105 Series

Part	Operating Temperature (Max)	Operating Temperature (Min)	Contact Finish - Mating	Shell Material	Shell Finish	Shielding	Color	Voltage Rating	Termination	Fastening Type	Number of Positions	Current Rating	Primary Material	Mounting Type	Orientation	Ingress Protection Description	Ingress Protection IP Rating	Shell Size - Insert	Features	Connector Type
Amphenol Tuchel Industrial C091 31H105 100 2	100 °C	-40 °C	Silver	Die Cast	Nickel	Shielded	Silver	60 V	Solder Cup	Threaded	5	7 A	Metal	Free Hanging (In-Line)	Keyed	Dust Tight Water Resistant Waterproof	IP65 IP67 IP69K	M16-5(S)	Stereo Strain Relief	Male Pins Plug
Amphenol Tuchel Industrial C091 31H105 101 2	100 °C	-40 °C	Silver	Die Cast	Nickel	Shielded	Silver	60 V	Solder Cup	Threaded	5	7 A	Metal	Free Hanging (In-Line)	Keyed	Dust Tight Water Resistant Waterproof	IP65 IP67 IP69K	M16-5(S)	Stereo Strain Relief	Male Pins Plug
