M52-040000S2545
ActiveHarwin Inc.
25+25 POS. MALE DIL VERTICAL SMT CONN. ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
M52-040000S2545
ActiveHarwin Inc.
25+25 POS. MALE DIL VERTICAL SMT CONN. ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M52-040000S2545 |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating | Flash |
| Contact Finish Thickness - Post | Flash |
| Contact Length - Mating | 4 mm |
| Contact Length - Mating | 0.157 in |
| Contact Material | Brass |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Insulation Height [z] | 0.098 in |
| Insulation Height [z] | 2.5 mm |
| Insulation Material | Nylon 6T, Polyamide (PA6T) |
| Mated Stacking Heights | 12.27 mm, 9.77 mm, 8.37 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 50 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch - Mating | 0.05 in |
| Pitch - Mating | 1.27 mm |
| Row Spacing - Mating [x] | 2.54 mm |
| Row Spacing - Mating [x] | 0.1 in |
| Shrouding | Unshrouded |
| Termination | Solder |
M52-040 Series
| Part | Contact Length - Post | Contact Length - Post | Contact Finish - Mating | Number of Positions Loaded | Material Flammability Rating | Termination | Insulation Height [z] | Insulation Height [z] | Mated Stacking Heights | Insulation Material | Fastening Type | Contact Shape | Contact Finish Thickness - Mating | Contact Material | Contact Length - Mating | Contact Length - Mating | Insulation Color | Mounting Type | Pitch - Mating | Pitch - Mating | Shrouding | Connector Type | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Overall Contact Length | Overall Contact Length | Contact Type | Number of Positions | Contact Finish Thickness - Post | Contact Finish - Post | Row Spacing - Mating [x] | Row Spacing - Mating [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Harwin Inc. | 0.091 in | 2.3 mm | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 7.1 mm 8.5 mm 11 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Through Hole | 0.05 in | 1.27 mm | Unshrouded | Header | 1 | -40 °C | 105 ░C | 8.8 mm | 0.346 in | Male Pin | |||||
Harwin Inc. | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 8.37 mm 9.77 mm 12.27 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Surface Mount | 0.05 in | 1.27 mm | Unshrouded | Header | 1 | -40 °C | 105 ░C | Male Pin | 20 | Flash | Gold | ||||||
Harwin Inc. | 0.091 in | 2.3 mm | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 7.1 mm 8.5 mm 11 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Through Hole | 0.05 in | 1.27 mm | Unshrouded | Header | 2 | -40 °C | 105 ░C | 8.8 mm | 0.346 in | Male Pin | 10 | 2.54 mm | 0.1 in | ||
Harwin Inc. | 0.091 in | 2.3 mm | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 7.1 mm 8.5 mm 11 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Through Hole | 0.05 in | 1.27 mm | Unshrouded | Header | 2 | -40 °C | 105 ░C | 8.8 mm | 0.346 in | Male Pin | 40 | Flash | Gold | 2.54 mm | 0.1 in |
Harwin Inc. | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 8.37 mm 9.77 mm 12.27 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Through Hole | 0.05 in | 1.27 mm | Unshrouded | Header | 2 | -40 °C | 105 ░C | Male Pin | 40 | Flash | Gold | 2.54 mm | 0.1 in | ||||
Harwin Inc. | Gold | All | UL94 V-0 | Solder | 0.098 in | 2.5 mm | 8.37 mm 9.77 mm 12.27 mm | Nylon 6T Polyamide (PA6T) | Push-Pull | Square | Flash | Brass | 4 mm | 0.157 in | Black | Through Hole | 0.05 in | 1.27 mm | Unshrouded | Header | 2 | -40 °C | 105 ░C | Male Pin | 50 | Flash | Gold | 2.54 mm | 0.1 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
M52-040 Series
Connector Header Through Hole 50 position 0.050" (1.27mm)
