M50-3601042R
ActiveHarwin Inc.
BOARD CONNECTOR, 20 CONTACT(S), 2 ROW(S), FEMALE, STRAIGHT, 0.05 INCH PITCH, SURFACE MOUNT TERMINAL, LOCKING, BLACK INSULATOR, SOCKET,
Deep-Dive with AI
Search across all available documentation for this part.
M50-3601042R
ActiveHarwin Inc.
BOARD CONNECTOR, 20 CONTACT(S), 2 ROW(S), FEMALE, STRAIGHT, 0.05 INCH PITCH, SURFACE MOUNT TERMINAL, LOCKING, BLACK INSULATOR, SOCKET,
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M50-3601042R |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 3 µin |
| Contact Finish Thickness - Mating | 0.076 µm |
| Contact Finish Thickness - Post | 2.5 µm |
| Contact Finish Thickness - Post | 98.4 µin |
| Contact Length - Mating | 3 mm |
| Contact Length - Mating | 0.118 in |
| Contact Material | Copper Alloy |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Features | Pick and Place |
| Insulation Color | Black |
| Insulation Height | 0.039 " |
| Insulation Height | 1 mm |
| Insulation Material | Thermoplastic |
| Mated Stacking Heights | 6.18 mm, 3.9 mm, 5.3 mm, 7 mm, 6.08 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Surface Mount |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch - Mating | 0.05 in |
| Pitch - Mating | 1.27 mm |
| Row Spacing - Mating | 0.05 in |
| Row Spacing - Mating | 1.27 mm |
| Shrouding | Unshrouded |
| Style | Board to Board, Cable |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.91 | |
| 10 | $ 2.48 | |||
| 100 | $ 2.10 | |||
| Digi-Reel® | 1 | $ 2.91 | ||
| 10 | $ 2.48 | |||
| 100 | $ 2.10 | |||
| Tape & Reel (TR) | 750 | $ 1.55 | ||
| 1500 | $ 1.52 | |||
| 3750 | $ 1.66 | |||
| 5250 | $ 1.60 | |||
Description
General part information
M50-360 Series
Connector Header Surface Mount 20 position 0.050" (1.27mm)
