| Adhesive | - | Rubber |
| Backing, Carrier | - | Crepe Paper, Treated, Paper |
| Color | - | Tan |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish - Post | Gold | Gold |
| Contact Finish Thickness - Mating | 30 Áin | 30 Áin |
| Contact Finish Thickness - Mating | 0.76 Ám | 0.76 Ám |
| Contact Finish Thickness - Post | 30 µin | 30 µin |
| Contact Finish Thickness - Post | 0.76 µm | 0.76 µm |
| Contact Material - Mating | Beryllium Copper | Beryllium Copper |
| Contact Material - Post | Beryllium Copper | Beryllium Copper |
| Contact Resistance | - | 15 - 25 mOhm |
| Convert From (Adapter End) | 15.24 mm | 15.24 mm |
| Convert From (Adapter End) | DIP | DIP |
| Convert From (Adapter End) | 0.6 in | 0.6 in |
| Convert To (Adapter End) | 0.6 in | 0.6 in |
| Convert To (Adapter End) | DIP | DIP |
| Convert To (Adapter End) | 15.24 mm | 15.24 mm |
| Current Rating (Amps) | 1 A | 1 A |
| Features | Closed Frame | Closed Frame |
| Housing Material | Polysulfone (PSU), Glass Filled | Polysulfone (PSU), Glass Filled, Polyethersulfone (PES) |
| Length | - | 60 yds |
| Length | - | 55 m |
| Length | - | 180 ft |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Through Hole | Connector, Through Hole |
| Number of Pins | 32 | 32 |
| Number of Positions or Pins (Grid) | - | 2 x 16, 1 x 32 |
| Number of Positions or Pins (Grid) | - | 32 |
| Number of Positions or Pins (Grid) | - | 32 |
| Number of Positions or Pins (Grid) | - | 32 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Pitch - Mating | 0.1 in | 0.1 in |
| Pitch - Mating | 2.54 mm | 2.54 mm |
| Pitch - Post | 2.54 mm | 2.54 mm |
| Pitch - Post | 0.1 in | 0.1 in |
| Shelf Life | - | 12 Months |
| Shelf Life Start | - | Date of Manufacture |
| Storage/Refrigeration Temperature | - | 70 °F |
| Storage/Refrigeration Temperature | - | 21 °C |
| Tape Type | - | Masking |
| Termination | Wire Wrap | Press-Fit, Solder, Wire Wrap |
| Termination Post Length | - | 0.11 - 0.13 in |
| Termination Post Length | - | 2.78 - 3.3 mm |
| Termination Post Length [x] | 0.62 in | 0.114 - 0.62 in |
| Termination Post Length [x] | 15.75 mm | 2.9 - 15.75 mm |
| Thickness | - | 6.3 mils |
| Thickness | - | 0.0063 " |
| Thickness | - | 0.16 mm |
| Type | - | 15.24 mm |
| Type | - | DIP, ZIF (ZIP), ZIF (ZIP), PGA, QFN, SIP |
| Type | - | 0.6 " |
| Usage | - | Medium Temp, Paint Bake |
| Width | - | 48 - 72 mm |
| Width | - | 1.89 - 2.83 " |
| Width | - | 0.47 - 3.78 in |
| Width | - | 12 - 96 mm |
