BQ24195LEVM-193
ActiveTexas Instruments
MODULE EVAL FOR BQ24195L-193
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
BQ24195LEVM-193
ActiveTexas Instruments
MODULE EVAL FOR BQ24195L-193
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24195LEVM-193 | BQ24195 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Battery Pack Voltage | - | 4.2 V |
| Charge Current - Max | - | 2.5 - 4.5 A |
| Contents | Board(s) | Board(s) |
| Current - Charging | - | Constant - Programmable |
| Embedded | False | False |
| Fault Protection | - | Over Current, Over Voltage, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Interface | - | I2C |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 24-VFQFN Exposed Pad |
| Primary Attributes | Li-Ion (1 Cell) | Li-Ion (1 Cell) |
| Secondary Attributes | I2C Interface(s) | I2C Interface(s) |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-VQFN (4x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24195L | BQ24195, BQ24195L |
| Voltage - Supply (Max) | - | 17 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | Box | 1 | $ 118.80 | |
| Digikey | Box | 1 | $ 118.80 | |
| Mouser Electronics | N/A | 1 | $ 118.80 | |
BQ24195 Series
I2C CONTROLLED 4.5A SINGLE CELL CHARGER WITH 5.1V, 2.1-A SYNCHRONOUS BOOST OPERATION 24-VQFN -40 TO 85
| Part | Supplier Device Package | Interface | Operating Temperature [Max] | Operating Temperature [Min] | Number of Cells | Battery Pack Voltage | Package / Case | Fault Protection | Battery Chemistry | Voltage - Supply (Max) [Max] | Charge Current - Max [Max] | Mounting Type | Current - Charging | Function | Primary Attributes | Secondary Attributes | Type | Embedded | Supplied Contents | Utilized IC / Part | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24195RGER | 24-VQFN (4x4) | I2C | 85 °C | -40 °C | 1 | 4.2 V | 24-VFQFN Exposed Pad | Over Current, Over Temperature, Over Voltage | Lithium Ion/Polymer | 17 V | 4.5 A | Surface Mount | Constant - Programmable | ||||||||
Texas Instruments BQ24195RGET | 24-VQFN (4x4) | I2C | 85 °C | -40 °C | 1 | 4.2 V | 24-VFQFN Exposed Pad | Over Current, Over Temperature, Over Voltage | Lithium Ion/Polymer | 17 V | 4.5 A | Surface Mount | Constant - Programmable | ||||||||
Texas Instruments BQ24195LRGET | 24-VQFN (4x4) | I2C | 85 °C | -40 °C | 1 | 4.2 V | 24-VFQFN Exposed Pad | Over Current, Over Temperature, Over Voltage | Lithium Ion/Polymer | 17 V | 2.5 A | Surface Mount | Constant - Programmable | ||||||||
Texas Instruments BQ24195LRGER | 24-VQFN (4x4) | I2C | 85 °C | -40 °C | 1 | 4.2 V | 24-VFQFN Exposed Pad | Over Current, Over Temperature, Over Voltage | Lithium Ion/Polymer | 17 V | 2.5 A | Surface Mount | Constant - Programmable | ||||||||
Texas Instruments BQ24195EVM-193 | Battery Charger | Li-Ion (1 Cell) | I2C Interface(s) | Power Management | Board(s) | BQ24195 | |||||||||||||||
Texas Instruments BQ24195LEVM-193 | Battery Charger | Li-Ion (1 Cell) | I2C Interface(s) | Power Management | Board(s) | BQ24195L | Board(s) |
