BQ25713EVM-017
ActiveDEVELOPMENT POWER MANAGEMENT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ25713EVM-017 | BQ25713 Series |
|---|---|---|
| Battery Chemistry | - | Multi-Chemistry |
| Contents | Board(s) | Board(s) |
| Fault Protection | - | Over Current, Over Voltage, Over Temperature |
| Function | Battery Charger | Battery Monitor, Battery Charger |
| Interface | - | I2C |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 4 |
| Number of Cells | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Secondary Attributes | On-Board Test Points | On-Board Test Points |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 32-QFN (4x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ25713 | BQ25713 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 178.80 | |
BQ25713 Series
I2C 1-4 cell NVDC Buck-Boost battery charge controller with USB type C PD support
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Fault Protection | Mounting Type | Supplier Device Package | Function | Number of Cells [Max] [custom] | Number of Cells [Min] [custom] | Interface | Battery Chemistry | Supplied Contents | Secondary Attributes | Type | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ25713RSNT | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage | Surface Mount | 32-QFN (4x4) | Battery Monitor | 4 | 1 | I2C | Multi-Chemistry | |||||
Texas Instruments BQ25713BRSNR | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage | Surface Mount | 32-QFN (4x4) | Battery Monitor | 4 | 1 | I2C | Multi-Chemistry | |||||
Texas Instruments BQ25713RSNR | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage | Surface Mount | 32-QFN (4x4) | Battery Monitor | 4 | 1 | I2C | Multi-Chemistry | |||||
Texas Instruments BQ25713BRSNT | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage | Surface Mount | 32-QFN (4x4) | Battery Monitor | 4 | 1 | I2C | Multi-Chemistry | |||||
Texas Instruments BQ25713EVM-017 | Battery Charger | Board(s) | On-Board Test Points | Power Management | Board(s) | BQ25713 |
Description
General part information
BQ25713 Series
This device is a synchronous NVDC buck-boost battery charge controller, offering a low component count, high efficiency solution for space constrained, 1s-4s battery charging applications.
The NVDC configuration allows the system to be regulated at battery voltage, but not drop below system minimum voltage. The system keeps operating even when the battery is completely discharged or removed. When load power exceeds input source rating, the battery goes into supplement mode and prevents the system from crashing.
The BQ25713/BQ25713B charges battery from a wide range of input sources including USB adapter, high voltage USB PD sources and traditional adapters.
