320X10559X
ActiveAmphenol CONEC
DSUB GENDER CHANGER DB25F DB25F
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
320X10559X
ActiveAmphenol CONEC
DSUB GENDER CHANGER DB25F DB25F
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 320X10559X |
|---|---|
| Connector Style | Gender Changer |
| Contact Finish | Gold |
| Contact Finish Thickness | 8 çin |
| Contact Finish Thickness | 0.203 çm |
| Convert From (Adapter End) | D-Sub, 25 Pin Female |
| Convert To (Adapter End) | D-Sub, 25 Pin Female |
| Current Rating (Amps) | 7.5 A |
| Housing Color | Yellow |
| Includes | 1 Connector, 4 Jack Screws |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Rows | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Voltage Rating | 125 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 8.54 | |
| 10 | $ 7.26 | |||
| 25 | $ 6.81 | |||
| 40 | $ 5.74 | |||
| 50 | $ 6.48 | |||
| 80 | $ 5.33 | |||
| 100 | $ 6.17 | |||
| 230 | $ 4.78 | |||
| 250 | $ 5.79 | |||
| 440 | $ 4.59 | |||
| 500 | $ 5.51 | |||
| 1000 | $ 5.25 | |||
Description
General part information
320X105 Series
Adapter Connector D-Sub, 25 Pin Female To D-Sub, 25 Pin Female Free Hanging (In-Line)
