50M080125 Series

Part	Material	Head Diameter	Screw Head Type	Length - Overall	Length - Below Head	Drive Type	Thread Diameter	Thread Pitch	Type	Head Height
Essentra Components 50M080125J030	Nylon	0.512 in	Hex Head	1.417 in	1.181 in	Hex Socket	8 mm	1.25 mm	Bolt
Essentra Components 50M080125I020	Nylon	0.681 in	Flat Head	0.787 in	0.606 in	Phillips	8 mm	1.25 mm	Machine Screw	0.181 in
Essentra Components 50M080125P016	Nylon	0.63 in	Pan Head	0.858 in	0.63 in	Phillips	8 mm	1.25 mm	Machine Screw	0.228 in
Essentra Components 50M080125G035	Nylon	0.63 in	Pan Head	1.614 in	1.378 in	Phillips	8 mm	1.25 mm	Machine Screw	0.236 in
Essentra Components 50M080125K010	Nylon	0.512 in	Hex Head	0.63 in	0.394 in	Slotted	8 mm	1.25 mm	Bolt
Essentra Components 50M080125R035	Nylon	0.201 in		1.472 in	1.378 in	Slotted	8 mm	1.25 mm	Set Screw
Essentra Components 50M080125J035	Nylon	0.512 in	Hex Head	1.614 in	1.378 in	Hex Socket	8 mm	1.25 mm	Bolt
Essentra Components 50M080125K016	Nylon	0.512 in	Hex Head	0.866 in	0.63 in	Slotted	8 mm	1.25 mm	Bolt
Essentra Components 50M080125J040	Nylon	0.512 in	Hex Head	1.811 in	1.575 in	Hex Socket	8 mm	1.25 mm	Bolt
Essentra Components 50M080125P010	Nylon	0.63 in	Pan Head	0.622 in	0.394 in	Phillips	8 mm	1.25 mm	Machine Screw	0.228 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources

No documents available
