Specification	516-056-540-325

Color	Gray
Connector Style	Rack and Panel
Connector Type	Housing for Non-Gendered Contacts
Connector Usage	Plug
Features	Jackscrew, Backshell
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	56
Number of Rows	9
Pitch	0.15 in

516-056 Series

...

Part	Note	Connector Usage	Mounting Type	Number of Rows	Features	Pitch	Number of Positions	Color	Connector Style	Connector Type
EDAC Inc. 516-056-000-330	Contacts Not Included	Plug	Free Hanging (In-Line)	9	Backshell	0.15 in	56	Gray	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-540-121	Contacts Not Included	Plug	Free Hanging (In-Line)	9	Backshell Guide Pin Jackscrew	0.15 in	56	Green	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-541-632	Contacts Not Included	Receptacle	Free Hanging (In-Line)	9	Backshell Jackscrew Socket Mating Guide	0.15 in	56	Green	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-540-420	Contacts Not Included	Receptacle	Free Hanging (In-Line)	9	Backshell	0.15 in	56	Gray	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-500-402	Contacts Not Included	Receptacle		9	Jackscrew Socket Mating Guide	0.15 in	56	Gray	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-541-415	Contacts Not Included	Receptacle	Free Hanging (In-Line)	9	Backshell Jackscrew	0.15 in	56	Gray	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-000-352	Contacts Not Included	Plug	Free Hanging (In-Line)	9	Backshell Guide Pin Jackscrew Socket	0.15 in	56	Gray	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-542-151	Contacts Not Included	Plug	Free Hanging (In-Line)	9	Backshell Guide Pin Jackscrew	0.15 in	56	Green	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-520-255	Contacts Not Included	Receptacle	Free Hanging (In-Line)	9	Backshell Jackscrew	0.15 in	56	Green	Rack and Panel	Housing for Non-Gendered Contacts
EDAC Inc. 516-056-500-226	Contacts Not Included	Receptacle	Free Hanging (In-Line)	9	Backshell Jackscrew Socket	0.15 in	56	Green	Rack and Panel	Housing for Non-Gendered Contacts
