CC2652PSIPMOTR

CC2652PSIPMOTR

Active
Texas Instruments

SIMPLELINK™ MULTIPROTOCOL 2.4-GHZ WIRELESS SYSTEM-IN-PACKAGE MODULE WITH INTEGRATED POWER AMPLIFIER

Find alt
CC2652PSIPMOTR

CC2652PSIPMOTR

Active
Texas Instruments

SIMPLELINK™ MULTIPROTOCOL 2.4-GHZ WIRELESS SYSTEM-IN-PACKAGE MODULE WITH INTEGRATED POWER AMPLIFIER

Find alt

Description

General part information

CC2652 Series

The SimpleLink™ CC2652P7 device is a multiprotocol 2.4-GHz wireless microcontroller (MCU) supportingThread,Zigbee, Matter,Bluetooth5.2 Low Energy, IEEE 802.15.4g, IPv6-enabled smart objects (6LoWPAN),TI 15.4-Stack(2.4 GHz), and concurrent multiprotocol through a Dynamic Multiprotocol Manager (DMM) driver. The CC2652P7 is based on an Arm®Cortex®M4F main processor and optimized for low-power wireless communication and advanced sensing ingrid infrastructure,building automation,retail automation,personal electronicsandmedical applications.

The CC2652P7 has a software defined radio powered by an Arm® Cortex® M0, which allows support for multiple physical layers and RF standards. The device supports operation in the 2360 to 2500-MHz frequency band. PHY and frequency switching can be done runtime through a dynamic multiprotocol manager (DMM) driver. The CC2652P7 has an efficient built-in PA that supports +10 dBm TX at 21 mA and +20 dBM TX at 101 mA in 2.4-GHz band. CC2652P7 has a receive sensitivity of -104 dBm for 125-kbps Bluetooth® Low Energy Coded PHY.

The CC2652P7 has a low sleep current of 0.9 µA with RTC and 144KB RAM retention. In addition to the main Cortex® M4F processor, the device also has an autonomous ultra-low power Sensor Controller CPU with fast wake-up capability. As an example, the sensor controller is capable of 1-Hz ADC sampling at 1-µA system current.

Technical Specifications

Parameters and characteristics for this part

SpecificationCC2652PSIPMOTR
Antenna TypeAntenna Not Included
Current - Receiving7.3 mA
Current - Transmitting (Max)33 mA
Current - Transmitting (Min)7.9 mA
Data Rate2 Mbps
Frequency (Max)2.48 GHz
Frequency (Min)2.4 GHz
Memory Size (Flash)352 kB
Memory Size (SRAM)88 kB
Memory TypeFlash, SRAM
ModulationDSSS, O-QPSK
Mounting TypeSurface Mount
Operating Temperature (Max)105 °C
Operating Temperature (Min)-40 °C
Package / Case73-SMD Module
Power - Output10 dBm
ProtocolThread, Zigbee®, Bluetooth v5.2
RF Family/Standard802.15.4, Bluetooth
Sensitivity-103 dBm
Serial InterfacesUART, SPI, I2C, JTAG, GPIO, I2S, ADC
Utilized IC / PartCC2652P
Voltage - Supply (Maximum)3.8 V
Voltage - Supply (Minimum)1.8 V
