BQ25601EVM-877
ActiveTexas Instruments
EVAIL MOD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ25601EVM-877 | BQ25601 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Battery Pack Voltage | - | 4.2 V |
| Charge Current - Max | - | 3 A |
| Current - Charging | - | Constant - Programmable |
| Fault Protection | - | Over Current, Over Voltage, Short Circuit, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Interface | - | I2C |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 24-WFQFN Exposed Pad |
| Primary Attributes | Li-Ion / Li-Pol (1 Cell) | Li-Ion / Li-Pol (1 Cell) |
| Programmable Features | - | Voltage, Current |
| Secondary Attributes | Graphical User Interface (GUI), I2C Interface(s) | Graphical User Interface (GUI), I2C Interface(s) |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-WQFN (4x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ25601 | BQ25601, BQ25601D |
| Voltage - Supply (Max) | - | 13.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 118.80 | |
BQ25601 Series
I2C 1CELL 3A BUCK BATTERY CHARGER WITH POWER PATH, USB DETECTION AND OTG
| Part | Battery Chemistry | Fault Protection | Number of Cells | Voltage - Supply (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Programmable Features | Supplier Device Package | Mounting Type | Charge Current - Max [Max] | Package / Case | Interface | Current - Charging | Type | Supplied Contents | Secondary Attributes | Utilized IC / Part | Function | Primary Attributes | Battery Pack Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ25601DRTWR | Lithium Ion/Polymer | Over Current, Over Temperature, Over Voltage, Short Circuit | 1 | 13.5 V | 85 °C | -40 °C | Current, Voltage | 24-WQFN (4x4) | Surface Mount | 3 A | 24-WFQFN Exposed Pad | I2C | Constant - Programmable | |||||||
Texas Instruments BQ25601EVM-877 | Power Management | Board(s) | Graphical User Interface (GUI), I2C Interface(s) | BQ25601 | Battery Charger | Li-Ion / Li-Pol (1 Cell) | ||||||||||||||
Texas Instruments BQ25601RTWR | Lithium Ion/Polymer | Over Temperature, Over Voltage | 1 | 13.5 V | 85 °C | -40 °C | 24-WQFN (4x4) | Surface Mount | 3 A | 24-WFQFN Exposed Pad | I2C | Constant - Programmable | 4.2 V | |||||||
Texas Instruments BQ25601DEVM-877 | Power Management | Board(s) | Graphical User Interface (GUI), I2C Interface(s) | BQ25601D | Battery Charger | Li-Ion / Li-Pol (1 Cell) | ||||||||||||||
Texas Instruments BQ25601RTWT | Lithium Ion/Polymer | Over Temperature, Over Voltage | 1 | 13.5 V | 85 °C | -40 °C | 24-WQFN (4x4) | Surface Mount | 3 A | 24-WFQFN Exposed Pad | I2C | Constant - Programmable | 4.2 V |
Description
General part information
BQ25601 Series
BQ25601 Battery Charger Power Management Evaluation Board
