PEG124YA1100QL1

Unknown

KEMET

CAP ALUM 1UF 20% 450V AXIAL TH

Search across all available documentation for this part.

Unknown

KEMET

CAP ALUM 1UF 20% 450V AXIAL TH

Technical Specifications

Parameters and characteristics for this part

Specification	PEG124YA1100QL1

Applications	General Purpose
Capacitance	1 µF
ESR (Equivalent Series Resistance)	49 Ohm
Height - Seated (Max) [Max] [z]	20 mm
Height - Seated (Max) [Max] [z]	0.787 "
Lifetime @ Temp.	5000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	Can, Axial
Polarization	Polar
Ripple Current @ Low Frequency	30 mA
Size / Dimension [diameter]	10 mm
Size / Dimension [diameter]	0.394 in
Tolerance	20 %
Voltage - Rated	450 V

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Mounting Type	Applications	Tolerance [Min]	Tolerance [Max]	Ripple Current @ Low Frequency	Voltage - Rated	ESR (Equivalent Series Resistance)	Operating Temperature [Max]	Operating Temperature [Min]	Polarization	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lifetime @ Temp.	Package / Case	Size / Dimension [x]	Size / Dimension [x]	Tolerance
KEMET PEG124YL2470QL1	20 mm	0.787 in	392.08 mA	Through Hole	General Purpose	-10 %	30 %	377 mA	450 V	1.2 Ohm	125 °C	-40 °C	Polar	47 µF	46 mm	1.811 in	2000 Hrs	Axial Can
KEMET PEG124YB1220QT1	10 mm	0.394 in		Through Hole	General Purpose	-10 %	30 %	43 mA	450 V	24 Ohm	105 ░C	-40 °C	Polar	2.2 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YB1220QL1	10 mm	0.394 in		Through Hole	General Purpose	-10 %	30 %	43 mA	450 V	24 Ohm	105 ░C	-40 °C	Polar	2.2 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YB1330QT1	10 mm	0.394 in	380 mA	Through Hole	General Purpose	-10 %	30 %	55 mA	450 V	17 Ohm	105 ░C	-40 °C	Polar	3.3 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YD1470QL1	13 mm	0.512 in	82.16 mA	Through Hole	General Purpose			79 mA	450 V	11 Ohm	105 ░C	-40 °C	Polar	4.7 µF	29 mm	1.142 in	5000 Hrs	Axial Can			20 %
KEMET PEG124YA1100QL1	10 mm	0.394 in		Through Hole	General Purpose			30 mA	450 V	49 Ohm	105 ░C	-40 °C	Polar	1 µF	20 mm	0.787 "	5000 Hrs	Axial Can			20 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

1 µF 450 V Aluminum Electrolytic Capacitors Axial, Can 49Ohm @ 100Hz 5000 Hrs @ 105°C
