PEG124YB1220QL1

Unknown

KEMET

CAP ALUM 2.2UF 450V AXIAL TH

Search across all available documentation for this part.

Unknown

KEMET

CAP ALUM 2.2UF 450V AXIAL TH

Technical Specifications

Parameters and characteristics for this part

Specification	PEG124YB1220QL1

Applications	General Purpose
Capacitance	2.2 µF
ESR (Equivalent Series Resistance)	24 Ohm
Lifetime @ Temp.	5000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	Can, Axial
Polarization	Polar
Ripple Current @ Low Frequency	43 mA
Size / Dimension [diameter]	0.394 in
Size / Dimension [diameter]	10 mm
Size / Dimension [x]	1.142 inches
Size / Dimension [x]	29 mm
Tolerance [Max]	30 %
Tolerance [Min]	-10 %
Voltage - Rated	450 V

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Mounting Type	Applications	Tolerance [Min]	Tolerance [Max]	Ripple Current @ Low Frequency	Voltage - Rated	ESR (Equivalent Series Resistance)	Operating Temperature [Max]	Operating Temperature [Min]	Polarization	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lifetime @ Temp.	Package / Case	Size / Dimension [x]	Size / Dimension [x]	Tolerance
KEMET PEG124YL2470QL1	20 mm	0.787 in	392.08 mA	Through Hole	General Purpose	-10 %	30 %	377 mA	450 V	1.2 Ohm	125 °C	-40 °C	Polar	47 µF	46 mm	1.811 in	2000 Hrs	Axial Can
KEMET PEG124YB1220QT1	10 mm	0.394 in		Through Hole	General Purpose	-10 %	30 %	43 mA	450 V	24 Ohm	105 ░C	-40 °C	Polar	2.2 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YB1220QL1	10 mm	0.394 in		Through Hole	General Purpose	-10 %	30 %	43 mA	450 V	24 Ohm	105 ░C	-40 °C	Polar	2.2 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YB1330QT1	10 mm	0.394 in	380 mA	Through Hole	General Purpose	-10 %	30 %	55 mA	450 V	17 Ohm	105 ░C	-40 °C	Polar	3.3 µF			5000 Hrs	Axial Can	1.142 inches	29 mm
KEMET PEG124YD1470QL1	13 mm	0.512 in	82.16 mA	Through Hole	General Purpose			79 mA	450 V	11 Ohm	105 ░C	-40 °C	Polar	4.7 µF	29 mm	1.142 in	5000 Hrs	Axial Can			20 %
KEMET PEG124YA1100QL1	10 mm	0.394 in		Through Hole	General Purpose			30 mA	450 V	49 Ohm	105 ░C	-40 °C	Polar	1 µF	20 mm	0.787 "	5000 Hrs	Axial Can			20 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

2.2 µF 450 V Aluminum Electrolytic Capacitors Axial, Can 24Ohm @ 100Hz 5000 Hrs @ 105°C
