M20-1060900

Active

Harwin Inc.

HEADER CONNECTOR,CABLE MOUNT,PLUG,9 CONTACTS,SKT,0.1 PITCH ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Harwin Inc.

HEADER CONNECTOR,CABLE MOUNT,PLUG,9 CONTACTS,SKT,0.1 PITCH ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Pitch [x]	Pitch [x]	Number of Positions	Connector Type	Insulation Material	Color	Note	Number of Rows	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Termination	Contact Type
Harwin Inc. M20-1060800	2.54 mm	0.1 in	8	Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
Harwin Inc. M20-1060200	2.54 mm	0.1 in	2	Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
Harwin Inc. M20-1060100			1	Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
Harwin Inc. M20-1060300	2.54 mm	0.1 in		Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
Harwin Inc. M20-1060900	2.54 mm	0.1 in	9	Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
Harwin Inc. M20-1061000	2.54 mm	0.1 in	10	Receptacle	Thermoplastic	Black	Contacts Not Included	1	Free Hanging (In-Line)	-25 °C	85 °C	Crimp	Female Socket
