2-1825011-1
ActiveTE Connectivity Raychem Cable Protection
ASF4204=4PDT AUTOSLIDE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsSWITCHES_CORE_PROGRAM_CATALOG
2-1825011-1
ActiveTE Connectivity Raychem Cable Protection
ASF4204=4PDT AUTOSLIDE
Deep-Dive with AI
DocumentsSWITCHES_CORE_PROGRAM_CATALOG
Technical Specifications
Parameters and characteristics for this part
| Specification | 2-1825011-1 |
|---|---|
| Actuator Length | Flush |
| Actuator Material | Polyamide (PA46), Nylon 4/6 |
| Actuator Type | Screwdriver Slot |
| Circuit | 4PDT |
| Contact Finish | Silver |
| Contact Material | Copper Alloy |
| Contact Timing | Shorting |
| Current Rating (Amps) | 300 mA |
| Electrical Life | 15000 Cycles |
| Features | Tape Seal |
| Mechanical Life | 15000 Cycles |
| Mounting Type | Through Hole |
| Operating Force | 950 gf |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -40 °C |
| Switch Function | On-On |
| Switch Travel | 2.79 mm |
| Termination Style | PC Pin |
| Voltage Rating - AC | 115 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 8.84 | |
| 10 | $ 8.44 | |||
| 29 | $ 7.68 | |||
| 116 | $ 6.63 | |||
| 261 | $ 6.03 | |||
| 522 | $ 5.59 | |||
| 1015 | $ 5.19 | |||
Description
General part information
ALCOSWITCH ASE/F Series
.3 A Slide Switch, Four Pole - Double Throw, Vertical, Copper Alloy, Single Actuator, 4 Position, On On, 115 VAC, 28 VDC, ALCOSWITCH ASE/F
