M12A-10PFFS-SH8C15

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, M12, A CODE, METAL, 1.5A, 10 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER,

Search across all available documentation for this part.

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, M12, A CODE, METAL, 1.5A, 10 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER,

Technical Specifications

Parameters and characteristics for this part

Specification	M12A-10PFFS-SH8C15

Color	Silver
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	1.5 A
Ingress Protection	IP68, IP69K
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Rear Side Nut
Number of Positions	10
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Orientation	A
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Zinc Alloy
Shell Size - Insert	M12-10
Shielding	Shielded
Termination	Wire Leads
Voltage Rating	30 VAC

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Current Rating (Amps)	Voltage Rating	Termination	Ingress Protection	Shell Material	Connector Type	Shell Finish	Color	Mounting Feature	Contact Finish - Mating	Shell Size - Insert	Primary Material	Orientation	Insert Material	Shielding	Number of Positions
Amphenol LTW M12A-10PFFS-SF8B15	-25 °C	85 °C	Copper Alloy	1.5 A	30 VAC	Wire Leads	IP68 IP69K	Zinc Alloy	Receptacle Female Sockets	Nickel	Silver	Bulkhead - Front Side Nut	Gold	M12-10	Metal	A	Polyamide (PA) Nylon Glass Filled	Shielded	10
Amphenol LTW M12A-10PFFS-SH8001	-40 °C	105 ░C	Copper Alloy	1.5 A	30 VAC		IP68 IP69K	Zinc Alloy	Receptacle Female Sockets	Nickel	Silver	Bulkhead - Rear Side Nut	Gold	M12-10	Metal	A	Polyamide (PA) Nylon Glass Filled	Shielded	10
Amphenol LTW M12A-10PFFS-SH8B15	-25 °C	85 °C	Copper Alloy	1.5 A	30 VAC	Wire Leads	IP68 IP69K	Zinc Alloy	Receptacle Female Sockets	Nickel	Silver	Bulkhead - Rear Side Nut	Gold	M12-10	Metal	A	Polyamide (PA) Nylon Glass Filled	Shielded	10
Amphenol LTW M12A-10PFFS-SF8001	-40 °C	105 ░C	Copper Alloy	1.5 A	30 VAC		IP68 IP69K	Zinc Alloy	Receptacle Female Sockets	Nickel	Silver	Bulkhead - Front Side Nut	Gold	M12-10	Metal	A	Polyamide (PA) Nylon Glass Filled	Shielded	10
Amphenol LTW M12A-10PFFS-SH8C15	-25 °C	85 °C	Copper Alloy	1.5 A	30 VAC	Wire Leads	IP68 IP69K	Zinc Alloy	Receptacle Female Sockets	Nickel	Silver	Bulkhead - Rear Side Nut	Gold	M12-10	Metal	A	Polyamide (PA) Nylon Glass Filled	Shielded	10

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position Circular Connector Receptacle, Female Sockets Wire Leads
